Chapter 3
Installation
Media Com-
partment, cont.
Ribbon Supply Hub
Ribbon Rewind Hub
Label Taken Sensor
(option)
Tear Bar
Cutter
(option)
Thermal Printhead
Printhead Lift Lever
Slack Absorber
20
The illustration below shows an EasyCoder 501 E with some options
installed. There are more options that are not illustrated here. Refer
the Appendix 1 for complete lists of standard features and options
for the EasyCoder 501 E.
Media Supply Hub
Liner Takeup
Batch Takeup
and Guide Shaft
Guide (option)
(option)
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
External Supply Guides
(option)
3-inch Adapter
Media Roll
Retainer
(option)
