Media, cont.
Self-Adhesive Strip
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
a
Media Width (including liner)
Maximum:
Minimum:
b
Liner
The liner must not extend more than a total of 1.6 mm (0.06
inches) outside the face material and should protrude equally
on both sides.
c
Media Width (excluding liner)
Maximum:
Minimum:
Media Type Setup
• Fix length strip
• Var length strip
This type of media is not suitable for use with a cutter.
Appendix 2 Media Specifi cations
120.0 mm
(4.72 inches)
25.4 mm
(1.00 inches)
118.4 mm
(4.66 inches)
23.8 mm
(0.94 inches)
129
