Summary of Contents for Christie M-Series

  • Page 1 M-Series U S E R M A N U A L 020-100009-02...

  • Page 3: Table Of Contents

    3.9 Input Switching & PIP Menu ......................3-46 3.10 Lamp Menu..........................3-48 3.11 Status ............................3-49 3.12 Using Multiple Projectors......................3-49 3.13 Remote Control of the Projector....................3-53 3.14 Alarm Conditions ........................3-53 4: Menu Tree 4.1 M-Series Menu Tree ........................4-1 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 4 6.7.10 Display Quality Appears to Drift from Good to Bad, Bad to Good .........6-4 6.7.11 Display has Suddenly Frozen.....................6-4 6.7.12 Colors in the Display are Inaccurate ..................6-4 6.7.13 Display is Not Rectangular ....................6-5 6.7.14 Display is “Noisy” ......................6-5 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 5 7.4.5 Dual Standard Definition, High Definition or Serial Digital Input ........7-8 7.5 Control Signal Compatibility ......................7-8 7.5.1 Remote Dual Frequency ......................7-8 7.5.2 Control Receiver ........................7-8 7.5.3 RS232...........................7-8 7.5.4 RS422...........................7-9 7.5.5 Ethernet..........................7-9 7.5.6 USB 2.0 Device Port ......................7-9 7.5.7 GPIO ............................7-9 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 6 7.7.5 Cosmetics ..........................7-11 7.8 Reliability and Serviceability.......................7-11 7.8.1 Reliability..........................7-11 7.8.2 Serviceability ........................7-11 7.9 Environment..........................7-11 7.9.1 Temperature/Humidity/Altitude...................7-11 7.10 Accessories and Service Components ..................7-12 7.10.1 Service Components ......................7-12 7.11 Regulatory..........................7-12 A: GPIO A.1 GPIO Port............................A-1 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 7: Labels And Marking

    Every effort has been made to ensure the information in this document is accurate and reliable. However, due to constant research, the information in this document is subject to change without notice. Christie Digital Systems assumes no responsibility for omissions or inaccuracies. Updates to this document are published regularly, as required.

  • Page 8: Typographical Notations

    • Operational states of modules appear capitalized, such as power ON/OFF. Purchase Record and Service Contacts Whether the projector is under warranty or the warranty has expired, Christie’s highly trained and extensive factory and dealer service network is always available to quickly diagnose and correct projector malfunctions.

  • Page 9: Projector Overview

    OSD display, and provide a quickly accessible interface to view error reporting. The functions on the OSD can also be controlled using the Christie Serial Protocol, via a serial or Ethernet connection to the projector. The Web interface provides access to the menu system as a Virtual OSD (On-screen display) and to features that maintain the projector’s software and...
  • Page 10 • Control with remote keypad, wired remote, or built-in keypad • Four input slots for Optional Input Modules Refer to Section 7 Specifications for a complete list of technical specifications. Table 1.3 M-Series Projectors Model Name Part Number DS+6K-M 118-013105-XX...

  • Page 11: 2: Installation And Setup

    NOTES: 1) Recommended for heaviest lenses such as 0.73:1 and 1.2:1. 2) Security screws MUST be installed when hoisting the projector overhead, or installing the projector in an overhead position. 7. Remove the front lens cap. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 12 Use of the lens security screws is required if the projector is hoisted or installed in an overhead position. 2-1 - L 2-2 - S IGURE NSTALLATION IGURE ECURITY CREW OCATION 2-3 - L IGURE LACEMENT M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 13 This prevents the line cord from inadvertent disconnection. Plug the 3-pronged plug end into a suitably rated grounded AC receptacle. Switch the projector ON. The switch is located just above the AC receptacle. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 14: Detailed Setup And Installation

    Section 3 Operation for more details. Detailed Setup and Installation Always power down the projector and disconnect all power sources before servicing or cleaning. Refer to Safety Warnings and Guidelines in Section 5 Maintenance. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 15: About The Projector

    LEDs to indicate their status. Cooling and Air Vents There are numerous air vents located around the projector. It is important these vents remain unobstructed. Adequate airflow through the projector will prevent it from overheating. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 16 • Zoom and Focus – There are two internal lens motors that allow for quick motorized adjustment of zoom and focus. Adjust zoom to fit the displayed image on the screen and adjust focus to improve the clarity of the image. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 17: Installation Considerations

    Rear Screen / Inverted Mount (ceiling) Installation Advantages Considerations • Projector is completely hidden. • Requires separate room. • Usually good ambient light rejection. • Installation cost is usually higher. • More difficult to access projector. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 18 150 times the height of the letter. Small text located too far from the eye will be illegible at a distance no matter how sharply and clearly it is displayed. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 19: Projector Position And Mounting

    IMPORTANT: Use the lens and screen size to calculate the precise throw distance using the tables provided in the Dealer Section of the Christie Website, PN 020-100221-XX. Due to lens manufacturing tolerances for lens focal length, actual throw distance can vary 5% between lenses with the same nominal throw ratio.
  • Page 20 Refer to Figure 2-9 - Vertical Offset Examples for illustrated examples of vertical offset. Table 2.1 Table 2.2 specify the vertical offset of each type of lens. 2-10 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 21 CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD 0.95” 3-CHIP 118-100117-XX ±119% ±643 pixels DLP® CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD SFL 0.95” 3- 118-101103-XX ±119% ±643 pixels CHIP DLP® CHRISTIE ILS LENS 1.25-1.6:1 SX+ / 1.16-1.49:1 HD 118-100111-XX ±102%...
  • Page 22 CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD 0.95” 3-CHIP 118-100117-XX ±100% ±525 pixels DLP® CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD SFL 0.95” 3- 118-101103-XX ±100% ±525 pixels CHIP DLP® CHRISTIE ILS LENS 1.25-1.6:1 SX+ / 1.16-1.49:1 HD 118-100111-XX ±73%...
  • Page 23 Section 2: Installation and Setup 2-9 - V IGURE ERTICAL FFSET XAMPLES M-Series User Manual 2-13 020-100009-02 Rev. 1 (04-2009)
  • Page 24 CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD 0.95” 3-CHIP 118-100117-XX ±42% ±403 pixels DLP® CHRISTIE ILS LENS 1.2:1 SX+ / 1.1:1 HD SFL 0.95” 3- 118-101103-XX ±42% ±403 pixels CHIP DLP® CHRISTIE ILS LENS 1.25-1.6:1 SX+ / 1.16-1.49:1 HD 118-100111-XX ±40%...
  • Page 25 CHRISTIE ILS LENS 1.25-1.6:1 SX+ / 1.16-1.49:1 HD 118-100111-XX ±45% ±315 pixels 0.95” 3-CHIP DLP® CHRISTIE ILS LENS 1.5-2.0:1 SX+ / 1.4-1.8:1 HD 0.95” 3- 118-100112-XX ±50% ±350 pixels CHIP DLP® CHRISTIE ILS LENS 2.0-2.8:1 SX+ / 1.8-2.6:1 HD 0.95” 3- 118-100113-XX ±50%...

  • Page 26: Mounting

    118-100108-XX. This mounting is recommended for those that want the projector out of plain view or have limited amount of space for the projector. For more information, contact your dealer. Use only the CHRISTIE approved ceiling mount kit designed for your projector. Refer to the installation instructions and safety guidelines provided in the kit.

  • Page 27: Basic Optical Alignment

    Figure 2-13 - Folded Optical Path . The position of the projector and mirror must be accurately set - if considering this type of installation call your dealer for assistance. M-Series User Manual 2-17 020-100009-02 Rev. 1 (04-2009)

  • Page 28: Advanced Optical Alignment

    4. Use a 5mm Allen™ key to loosen the 3 locking setscrews on the lens mount, see Figure 2-16 - Screw Locations, below. NOTE: The setscrews must be backed out several turns, so that they do not contact the inner lens mount plate. 2-18 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 29 10. If further action is required. Repeat #2. 11. Lock the setscrews, and re-check the boresight quality. Tighten the setscrew enough to ensure they will not shift. M-Series User Manual 2-19 020-100009-02 Rev. 1 (04-2009)

  • Page 30: Powering Down

    WEB USER INTERFACE (UI) 1. From the Main Tab, Select Power>OFF. NOTE: A window will display for confirmation on powering down, see Figure 2-18. 2. Select Yes. 2-18 - P IGURE OWERING NTER 2-20 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 31: Connecting Communications

    As an alternative to the projector’s keypad or remote, you may wish to communicate with the projector using a PC or other controller. Such a device sends commands and receives feedback via serial links (RS232 and RS422), or Ethernet communications to the projector, refer to the Serial Command document provided in the Dealer Section of the Christie Website, PN 020-100224-XX.
  • Page 32 Section 3 Operation for further information about setting up and using a projector connected via Ethernet, and the Serial Command document provided in the Dealer Section of the Christie Website, PN 020-100224-XX. Connecting Multiple Projectors To connect multiple projectors in a network with serial communication: RS232 NETWORK: 1.
  • Page 33 Ethernet port to a hub belonging to the network. A controller or PC must also be connected to the hub, see Figure 2-23 - Ethernet Network Setup. NOTE: A wireless router can be used to communicate to the projectors via 802.11b/g. M-Series User Manual 2-23 020-100009-02 Rev. 1 (04-2009)
  • Page 34 RS232 linking available between these projectors. For example, you may want to use both an RS422-compatible controller and an Ethernet-connected PC for working with a network of projectors linked via their RS232 in/out ports. 2-24 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 35 I/O devices. Refer to Appendix A, Figure A-1 - GPIO Connector for complete details on pin configuration and how to program the GPIO. 2-25 - I IGURE NPUT ANEL M-Series User Manual 2-25 020-100009-02 Rev. 1 (04-2009)

  • Page 36: Status Leds

    Flashing Green - the lamp is being switched off for its regeneration period to extend lamp life (typically 15 minutes every 24 hours) Power Green - on Amber - standby Shutter Green - shutter is open 2-26 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 37: Connecting Sources

    The PWR on the left side indicates power is applied, and that the card is initialized. The LEDs to the right side of the corresponding connectors indicate that a valid signal is detected. In the case of the output’s, the LED indicates a signal is currently being looped out. M-Series User Manual 2-27 020-100009-02 Rev. 1 (04-2009)
  • Page 38 2 analog signals at the same time. There are 4 LEDs on the module faceplate. PWR indicates power is applied and the card is initialized, and the other 3 on the right side of the corresponding connectors indicate that a valid signal has been detected. 2-28 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 39 4, 5, and 6 (Component input grouping must also be selected in the projector’s menu - Section 3 Operation. The remaining LEDs are each associated with one of the inputs, and indicate a valid signal has been detected on that input. M-Series User Manual 2-29 020-100009-02 Rev. 1 (04-2009)

  • Page 41: Using The Remote Keypad Or Built-In Keypad

    3 Operation This section describes the controls and switches used for basic projector operation once it is properly installed, aligned and configured by a CHRISTIE accredited service technician. Refer to Safety Warnings and Guidelines in Section 5 Maintenance. Using the Remote Keypad or Built-In Keypad The projector is typically controlled using one of the following keypads: •...
  • Page 42 Section 3: Operation Remote Keypad 3-1 - R IGURE EMOTE EYPAD M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 43 • Blue, a functionality is available that is relevant to the built-in LCD only and will not affect the displayed image from the projector • Off, the key is disabled in the current context M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 44: Remote Keypad Commands

    These parameters are listed in Table 3.1 - Auto Setup. An auto setup can save time in perfecting a display and you can modify the adjustments as desired. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 45 (i.e., “crushed”). Conversely, low contrast causes dim images. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 46 (open) to guarantee the correct state (useful if you are unsure of the present state). Alternatively, RROW press S to toggle from the present on/off state. A closed shutter blanks the display (turns it to HUTTER HUTTER M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 47 NOTE: E does not save changes within text editing boxes (including number editing of a slide bar value) or within pull-down lists. It acts as a “cancel” in these cases. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 48: Navigating The Menus

    Locked items or items that do not pertain to the current action or condition appear dimmed and cannot be selected. When finished with a function menu: • Press E to return to the previous screen. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 49 Hold for continuous adjustment. Or press E to activate a slide bar text box for NTER specific number entry via the keypad and then press E to save (or press E to cancel). NTER M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 50 E to activate its adjacent edit window. Any previously entered text is displayed with its first NTER character highlighted in a square cursor, signifying that this character is ready for editing. 3-10 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 51 If you press any non-numbered key, the number entered up to that point is accepted and updated as the new value. Press E to cancel editing of numerical values. M-Series User Manual 3-11 020-100009-02 Rev. 1 (04-2009)

  • Page 52: Using Inputs And Channels

    In general, the image from the new source will be as large as possible without losing its aspect ratio. This and other default image settings depend on the incoming source. 3-12 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 53: Channel Setup Menu

    Main menu. To display the Channel Setup menu, press 3, or move the highlight to the Channel Setup option and press E . The Channel Setup menu will appear NTER (see sample below). M-Series User Manual 3-13 020-100009-02 Rev. 1 (04-2009)
  • Page 54 Copying channels is a quick method for creating numerous channels, each of which can then be edited and adjusted for a variety of presentations in the future. 3-14 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 55 CHANNEL EDIT — STEP 2 To edit parameters shown in the Channel Setup menu, select the relevant channel and press E . The NTER Channel Edit menu will appear similar to the sample shown below. M-Series User Manual 3-15 020-100009-02 Rev. 1 (04-2009)
  • Page 56 You cannot use Auto Setup with a locked channel. • PREVIOUS CHANNEL: Select this option to see or change Channel Edit settings for the previous channel in the Channel Setup list. 3-16 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 57: Adjusting The Image

    Refer to if you need help using any of the options and controls. Changes made in the Size and Position menu are applied immediately and are saved when you exit the menu (press E or M 3-17 - S IGURE IZE AND OSITION M-Series User Manual 3-17 020-100009-02 Rev. 1 (04-2009)
  • Page 58 For example, for a source with a native resolution of 800 x 600, “No Resizing” in an SXGA+ pro- jector will use the central 800 x 600 pixels and have a black border—the black border areas are unused areas, see below. 3-18 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 59 (called “letterboxed”). 3-22 - F IGURE IDTH • “FULL HEIGHT” fills the display from top-to-bottom. Depending on the source, this may create borders. 3-23 - F IGURE EIGHT M-Series User Manual 3-19 020-100009-02 Rev. 1 (04-2009)
  • Page 60 NOTE: The value shown represents where the approximate center of the image lies in relation to the total number of pixels available vertically. This varies widely according to the signal—watch the image while adjusting. 3-20 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 61 Active Input Window 720x483 Active Input Window 720x483 Top Blank Top Blank Bottom Blank Bottom Blank Left Blank Left Blank Right Blank Right Blank 3-26 - B PIP I IGURE LANKING OF A MAGE M-Series User Manual 3-21 020-100009-02 Rev. 1 (04-2009)

  • Page 62: Image Settings Menu

    • RGB signals in NTSC, PAL, SECAM frequency ranges. • Scan-doubled sync-on-green. • Scan-quadrupled sync-on-green. For these signals, change the color Space to RGB, and then define a new channel for future use. 3-22 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 63 This slide bar adjusts the color saturation level. Lower settings produce less saturated colors, for example a setting of “0” produces a black and white image. If the color level is too high, colors will be overpowering and unrealistic. M-Series User Manual 3-23 020-100009-02 Rev. 1 (04-2009)
  • Page 64 As an example for 8 bit space, full range RGB uses levels 0(black) to 255(white). A limited CE range is 16-235 for 8-bit video sources. 3-24 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 65 4. If black levels are too high (and/or whites are too low, which is rare), you likely have a noisy source that is producing skewed input levels. Enable “Auto” in the Input Levels menu. Wait for all six values to M-Series User Manual 3-25...
  • Page 66 6. Repeat Steps 3-5 with the two remaining primary colors. When each primary color shows one optimized black band and white (or colored) band, the input levels for this source are correctly set. Upon exiting the Input Levels menu, the Peak Detector checkbox will clear. 3-26 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 67 1.0 while the control is increasing and likewise a linear transform toward a gamma of 3.0 as the control is decreasing. The control should only be adjusted to compensate for ambient conditions. To correct a particular source only, use the Gamma control. M-Series User Manual 3-27 020-100009-02 Rev. 1 (04-2009)
  • Page 68 Allows a snap shot of the main image to be presented on the right side of the screen to allow evaluation of advanced image processing features. All resizing controls are honoured on both images; 3-28 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 69 NOTES 1) Dynamic iris should not be used on blends, as this could result in image distortion. 2) Dynamic mode is only permitted in Dual lamp mode. If the global setting is set to “Per Channel” while in M-Series User Manual 3-29...
  • Page 70 It is often best to adjust the sensitivity and white compression together to find the optimal settings. • COPY FROM: This control allows you to copy the Dynamic Iris Settings from an existing profile to the current profile. 3-30 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 71: Configuration - Adjusting System Parameters And Advanced Controls

    If you change channels, the lens position will change as the new signal is being displayed.When ILS is not enabled, the lens is controlled independently of channels or input signals. M-Series User Manual 3-31 020-100009-02 Rev. 1 (04-2009)
  • Page 72 If this condition persists for an additional time-out period, the projector will automatically go to Standby mode. The presence of any activity within this combined interval will cancel Auto Shutdown and return the projector to normal operation. 3-32 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 73 2. Adjust Horizontal Shift and Vertical Shift slide bars to move the menu to the desired location. NOTE: Avoid locations too close to a corner or edge to prevent cropping of larger menus. • HORIZONTAL SHIFT AND VERTICAL SHIFT: Shift your menus as desired, creating a customized menu location. M-Series User Manual 3-33 020-100009-02 Rev. 1 (04-2009)
  • Page 74 • Start-up And No Signal – A splash screen appears at start-up and at any time when there is no signal. To add your own splash screen in addition to the default “Christie logo” splash screen, use the Web UI to download the desired bitmap (.bmp) file to the projector.
  • Page 75 3002. If so, enter a new valid port number here. It is highly recommended not to use a port # below 1000, as these ports are typically reserved for and used by common IP applications. M-Series User Manual 3-35...
  • Page 76 3-34 - H IGURE ORIZONTAL EYSTONE All settings to adjust keystone are in the Geometry Correction submenu. Brightness Uniformity, Edge Blending and Black Level Blending should be disabled before performing Keystone adjustments. 3-36 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 77 Coarse Adjustment checkbox to apply Brightness Uniformity settings with a large granularity. Coarse Adjustment helps identify brightness changes and accelerates projector response time while adjusting settings. To disable the Brightness Uniformity function, delete the Brightness Uniformity Enable checkmark. M-Series User Manual 3-37 020-100009-02 Rev. 1 (04-2009)
  • Page 78 Double-check that all WHITES and LIGHT OUTPUT are well-matched. IMPORTANT! b. Enable the Brightness Uniformity checkbox. This will enable access to the uniformity controls and will apply the settings to your image. 3-38 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 79 • Adjust corner White Uniformity last—each corner adjustment affects only this quadrant. M-Series User Manual 3-39 020-100009-02 Rev. 1 (04-2009)
  • Page 80 Edge blending software controls are located in the two-page Edge Blending submenu— access via Configuration menu, then go to the 3-37 - E Geometry and Color menu and select Edge IGURE LENDING ONCEPT 3-40 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 81 5. Re-adjust width (both projectors) until the overly bright band at the midpoint of the overlapping blends disappears or just changes to very light gray. For the shared edge, use the same Blend Width setting on M-Series User Manual 3-41...
  • Page 82 For example, changing the x/y coordinates for red may move the color closer to orange or closer to violet, which will in turn affect all displayed colors having a red component. Adjust the slide bars or 3-42 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 83 “seamless” image. (Edge blending smooths white levels, and if edge blending is not in use, Black Level Blending is disabled.) NOTES: 1) Adjust white levels before adjusting black levels. 2) Blinders are recommended for fixed installations. M-Series User Manual 3-43 020-100009-02 Rev. 1 (04-2009)
  • Page 84 Edge blending must be enabled in order to use the Black Level Blending features. The use of Black Level Blending feature and the use of Christie Twist module are mutually exclusive. If Christie Twist is installed and Black Level Blending is desired: 1.
  • Page 85 • TEST PATTERN COLOR SWAP: This function swaps the green and red color when drawing the Grid test pattern, and may be helpful when adjusting convergence on the projector. M-Series User Manual 3-45 020-100009-02 Rev. 1 (04-2009)

  • Page 86: Input Switching & Pip Menu

    Toggle the current PIP relationship so that the primary (main) image becomes secondary (PIP), and the secondary image becomes primary. Swapping is available only when PIP is enabled. NOTE: There may be a slight delay when swapping the Primary and Secondary images. 3-46 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 87 When enabled, the system will continually search for the next valid signal when no signal is present or when loss of sync occurs on the current user selected input. In the case of multiple signals to choose from, the order is based on slot, followed by inputs on that slot. M-Series User Manual 3-47 020-100009-02 Rev. 1 (04-2009)

  • Page 88: Lamp Menu

    • LAMP INTENSITY: Adjust the lamp intensity to% of full. This value is used as a target value by the LiteLOC system to maintain constant intensity. • YNF: Refer to 3.7 Image Settings Menu. 3-48 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 89: Status

    Alternatively, you may want to add projectors to a hub on an Ethernet network. See Figure 2-22 - Mixed Network for full routing details. M-Series User Manual 3-49 020-100009-02 Rev. 1 (04-2009)
  • Page 90 “Max Drives” color gamut for this projector. NOTE: The values shown in one (any) of the displays. Use the “Copy From” function to copy them into a “User” gamut in one projector. 3-50 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 91 3-42 - C X/Y V IGURE ALUES INTO ALL ROJECTORS 6. In each projector, judge by eye and adjust x/y coordinates slightly in the following manner: M-Series User Manual 3-51 020-100009-02 Rev. 1 (04-2009)
  • Page 92 NOTE: Adjustments here define new x/y coordinates in the Color Adjustments by X,Y menu. For best results, use this menu after doing the color adjustment procedure. 3-44 - C IGURE OLOR ATCHING SING OLOR ATURATION 3-52 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 93: Remote Control Of The Projector

    VIA ASCII MESSAGING — Connect a serial link between your controller and the RS232 or RS422 port (recommended), or open an Ethernet socket (i.e., Telnet) between your controller and the valid projector address. Valid ASCII codes and messages are documented in the Christie Serial Communications document available at the Christie website.
  • Page 94 Section 3: Operation 3-45 - E IGURE XAMPLE OF LARM ONDITION 3-54 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 95: 4: Menu Tree

    4 Menu Tree M-Series Menu Tree M-Series User Manual 020-100009-02 Rev. 1 04-2009...
  • Page 97 Section 4: Menu Tree M-Series User Manual 020-100009-02 Rev.1 (04-2009)
  • Page 98 Section 4: Menu Tree M-Series User Manual 020-100009-02 Rev.1 (04-2009)
  • Page 99 Section 4: Menu Tree M-Series User Manual 020-100009-02 Rev.1 (04-2009)

  • Page 101: Safety Warnings And Guidelines

    Position all cables where they cannot contact hot surfaces or be pulled or tripped over. All installation and maintenance procedures must be performed by a CHRISTIE accredited service technician. Projector must be operated in an environment that meets operating specifications, as...

  • Page 102: Lamp Precautions

    NOTE: Do not obstruct the air exchange to the projector. 5.2.2 Optional Filters Use only special, high efficiency Christie approved filters. This projector is not equipped with fan finger guards. Keep fingers away from the fan blades when replacing filter.

  • Page 103: Maintenance Of Optics

    Maintenance of optical components requires a qualified service technician. Inspect exposed optical surfaces periodically in a clean, dust-free environment using a flashlight. Never touch an optical surface with your bare hands. Always wear latex lab gloves. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 104: Cleaning The Lens

    Turn off the lamps using the remote keypad or the built-in keypad with the lamp OFF command (see Step 5) or by opening the lamp door. NOTE: The lamps will turn off automatically when the lamp door is open. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 105 NOTES: 1) If the lamps were turned off with the OFF command in step 1, they will have to be manually turned on. 2) If the lamps were turned off by opening the door, then they will automatically turn on again when the door is closed. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 107: Power

    If the projector is not operating properly, note the symptoms and use this section as a guide to resolve the problem. If the problem cannot be resolved. contact your dealer for assistance. NOTE: A CHRISTIE accredited service technician is required when opening an enclosure to diagnose any “probable cause”.

  • Page 108: Flicker, Shadows Or Dimness

    “OSD: off” press and hold the OSD soft key on the built-in keypad. The LCD will read “OSD on” and press Menu key 2. Press and hold OSD key on the remote keypad for 2-3 seconds, then press the Menu key on the remote keypad. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 109: Ethernet

    2. The horizontal and vertical scan frequency of the input signal may be out of range for the projector. Refer Section 7 Specifications for scan frequency ranges. 3. The sync signal may be inadequate. Correct the source problem. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 110: The Display Is Faint

    1. The color, tint, color space and/or color temperature settings may require adjustment at your input source. 2. Try Auto Setup. 3. Ensure signal connections are correct. 4. Ensure the proper channel for this source is being used. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 111: Display Is Not Rectangular

    4. If the distance between the input source device and the projector is greater than 25 feet, signal amplifica- tion/conditioning may be required. 5. If the source is a VCR or off-air broadcast, detail may be set too high. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 113: Image Performance

    7 Specifications This section provides detailed M-Series specifications, including: Due to continuing research, specifications are subject to change without notice. Image Performance 7.1.1 Pixel Format 1080p (H x V square pixels) 1920 x 1080 1080p Imaging Device & Configuration Dark Metal 4 DMD, 3 chip, 0.95” diagonal...

  • Page 114: Contrast

    0.148+-0.020 0.045+-0.025 7.1.7 Gamma Default Gamma (all points from 10 to 90 2.2 + linear segment IRE) Adjustable Gamma range 1.0 to 3.0 7.1.8 Grayscale/Color Resolution Resolution 10 bits (non-linear) min. (Gamma encoded) M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 115: Color Temperature

    350W models, 8 foot wide for 200W models. Blemishes are defined as per TI Specification 2506811. Red screen No blemishes Green screen No blemishes Blue screen No blemishes White screen No blemishes Black screen No blemishes M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 116: Pixel Defects

    Travel time stop to stop Zoom and Focus 10 sec nominal (depends on lens type) Offsets 5 sec (nominal (depends on lens type) Manual Lens Movement Manual over-ride permissible for zoom and focus M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 117: Projection Lens Compatibility

    User selectable optical color switch (in or out) to enhance color space Configurable per channel 7.2.9 Constant Lamp Output Management  Automatically adjusts lamp output to maintain LiteLOC constant lumens setting within operating range of lamp. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 118: Shutter

    Native format adjustment Optional global aspect ratio setting can be set for projector allowing for automatic scaling of all input images to required output format Arbitrary Gamma User definable gamma curves M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 119: Image Processor Performance

    1 dual link DVI-I 1 analog 15-pin VGA Color spaces/signal types HDCP support A/D conversion 10 bits for single link DVI input 8 bits for dual link DVI inputs Frequency 165 MPixel/s analog M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 120: Video Decoder Input

    Modulation (carrier) frequency Dual frequency (38 kHz, 455 kHz) 7.5.3 RS232 Number of ports Connector 1 female 9-pin Dsub (IN) 1 male 9-pin Dsub (OUT) Max bit rate 115.2 kbps Flow control Xon/Xoff M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 121: Rs422

    50/60 Hz AC Input Coupler 15 A, 250 VAC Type of connector IEC 320-C14 with wire cable clamp Line Cord 14AWG type FT1 with plug, NEMA 5-15P, 15A Inrush Current 60 A max M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 122: Lamp Specification

    Maximum shipping dimensions (L x W x H) 680mm (26.5”) x 650mm (25.6”) x 458mm (18”) 7.7.2 Adjustment Product Alignment 2” of vertical adjustment on 2 front feet 1” of vertical adjustment on single rear foot 7-10 M-Series User Manual 020-100009-02 Rev. 1 (04-2009)

  • Page 123: Weight

    1 minute Environment 7.9.1 Temperature/Humidity/Altitude Operating temperature range 5 to 40 degrees C Storage temperature range -40 to 70 degrees C Humidity range 10% to 80%, non condensing Operating Altitude 10,000 ft. maximum M-Series User Manual 7-11 020-100009-02 Rev. 1 (04-2009)

  • Page 124: Accessories And Service Components

    003-100856-XX DLV1920-DL, DLV1400-DL Lamp (350W); HD10K-M, Roadster HD10K-M, 003-100857-XX DS+10K-M, Roadster S+10K-M Air Filter Dust M-Series (Package of 6) 118-100104-XX Air Filter Fog M-Series (Package of 6) 118-100105-XX 7.11 Regulatory This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC).

  • Page 125: Gpio Port

    Pin 7 GPIO 5 Pin 8 GPIO 6 Pin 9 GPIO 7 The serial cable required for connecting the external device to the projector’s GPIO connector, must be compatible with the external device. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
  • Page 126 Reply of pin configurations - pins 2, 3 & 4 are Inputs, pins 6, 7, 8 & 9 are Outputs NOTE: The strings in the commands refer to pins 2, 3, 4, 6, 7, 8, 9 in order from left to right. M-Series User Manual 020-100009-02 Rev. 1 (04-2009)
