Limitation List
Start IP
End IP
Maximum Sessions
Maximum P2P Sessions
Add
Edit
Delete
Administration Message
Index (1-15) in Schedule
Setup
4 . 7 . 2 B a n d w i d t h
4 . 7 . 2 B a n d w i d t h
The downstream or upstream from FTP, HTTP or some P2P applications will occupy large
of bandwidth and affect the applications for other programs. Please use Limit Bandwidth to
make the bandwidth usage more efficient.
In the Bandwidth Management menu, click Bandwidth Limit to open the web page.
LAN.
Displays a list of specific limitations that you set on this web
page.
Defines the start IP address for limit session.
Defines the end IP address for limit session.
Defines the available session number for each host in the
specific range of IP addresses. If you do not set the session
number in this field, the system will use the default session
limit for the specific limitation you set for each index.
Defines the available session number for P2P application.
Adds the specific session limitation onto the list above.
Allows you to edit the settings for the selected limitation.
Remove the selected settings existing on the limitation list.
Type the words which will be displayed when reaches the
maximum number of Internet sessions permitted.
You can type in four sets of time schedule for your request.
All the schedules can be set previously in Application >>
Schedule web page and you can use the number that you
have set in that web page.
L i m i t
L i m i t
173
Vigor2710 Series User's Guide
