PPPoE Pass-through
WAN Connection
Detection
WAN Backup Setup
Vigor2710 Series User's Guide
for the router.
The router offers PPPoE dial-up connection. Besides, you also
can establish the PPPoE connection directly from local clients to
your ISP via the Vigor router. When PPPoA protocol is selected,
the PPPoE package transmitted by PC will be transformed into
PPPoA package and sent to WAN server. Thus, the PC can access
Internet through such direction.
For Wired LAN – If you check this box, PCs on the same
network can use another set of PPPoE session (different with the
Host PC) to access into Internet.
For Wireless LAN – If you check this box, PCs on the same
wireless network can use another set of PPPoE session (different
with the Host PC) to access into Internet.
VLAN Enable - Enable the function of VLAN with tag. The
router will add specific VLAN number to all packets while
sending them out. Please type the tag value and specify the
priority for the packets sending by the router.
VID– Type the value as the VLAN ID number. The range is form
0 to 4095.
Priority – Type the packet priority number for such VLAN. The
range is from 0 to 7.
Such function allows you to verify whether network connection is
alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you have
to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
3G USB Modem – If you have installed a 3G USB modem on the
router, please enable Dial Backup Mode to perform file backup
via USB device. After choosing Enable, please click the 3G USB
Modem link to access into the following page for configuring
detailed settings.
34
