Online status for DHCP
Detailed explanation is shown below:
Primary DNS
Secondary DNS
LAN Status
IP Address
TX Packets
RX Packets
WAN1 Status
Line
Name
Mode
Up Time
IP
GW IP
TX Packets
TX Rate
RX Packets
RX Rate
Note: The words in green mean that the WAN connection of that interface (WAN1) is
ready for accessing Internet; the words in red mean that the WAN connection of that
interface (WAN1) is not ready for accessing Internet.
2 . 6 . 2 V i r t u a l W A N
2 . 6 . 2 V i r t u a l W A N
Such page displays the virtual WAN connection information.
Virtual WAN are used by TR-069 management, VoIP service and so on.
Displays the IP address of the primary DNS.
Displays the IP address of the secondary DNS.
Displays the IP address of the LAN interface.
Displays the total transmitted packets at the LAN interface.
Displays the total number of received packets at the LAN interface.
Displays the physical connection (Ethernet) of this interface.
Displays the name set in WAN1/WAN web page.
Displays the type of WAN connection (e.g., PPPoE).
Displays the total uptime of the interface.
Displays the IP address of the WAN interface.
Displays the IP address of the default gateway.
Displays the total transmitted packets at the WAN interface.
Displays the speed of transmitted octets at the WAN interface.
Displays the total number of received packets at the WAN
interface.
Displays the speed of received octets at the WAN interface.
