SysLog Access Setup
Router Name
Server IP Address
Destination Port
Enable syslog message
Mail Alert Setup
Send a test e-mail
SMTP Server
SMTP Port
Mail To
Return-Path
Authentication
User Name
Password
Enable E-mail Alert
Click OK to save these settings.
For viewing the Syslog, please do the following:
1. Just set your monitor PC's IP address in the field of Server IP Address
2. Install the Router Tools in the Utility within provided CD. After installation, click on
the Router Tools>>Syslog from program menu.
3. From the Syslog screen, select the router you want to monitor. Be reminded that in
Network Information, select the network adapter used to connect to the router.
Otherwise, you won't succeed in retrieving information from the router.
Vigor2710 Series User's Guide
Enable - Check Enable to activate function of syslog.
Syslog Save to – Check Syslog Server to save the log to
Syslog server.
Display the name for such router configured in System
Maintenance>>Management.
If there is no name here, simply lick the link to access into
System Maintenance>>Management to set the router name.
The IP address of the Syslog server.
Assign a port for the Syslog protocol.
Check the box listed on this web page to send the
corresponding message of firewall, VPN, User Access, Call,
WAN, Router/DSL information to Syslog.
Check "Enable" to activate function of mail alert.
Make a simple test for the e-mail address specified in this
page. Please assign the mail address first and click this button
to execute a test for verify the mail address is available or not.
The IP address of the SMTP server.
Assign a port for the SMTP server.
Assign a mail address for sending mails out.
Assign a path for receiving the mail from outside.
Check this box to activate this function while using e-mail
application.
Type the user name for authentication.
Type the password for authentication.
Check the box to send alert message to the e-mail box while
the router detecting the item(s) you specify here.
