A S S E M B L Y M A N U A L

WESTLAND

LYSANDER Mk.III 55cc

" Graphics and speciications may change without notice " .

Code : SEA216

Speciications:

Wingspan---------------118 in (299.7 cm).

Wing area---------------1471 sq.in (94.9 sq.dm).

Weight-------------------22 lbs (10 kg).

Length-------------------70.4 in (178.8 cm).

Engine-------------------50-60cc gasoline - 2 stroke

----------------------------60-90cc - 4 stroke

----------------------------OS & Saito 5 Cylinder Radial

Radio---------------------6 channels with 8 servos.

Electric conversion: Optional.

Table of Contents

Need help?

Do you have a question about the WESTLAND LYSANDER Mk.III 55cc and is the answer not in the manual?

Questions and answers

Summary of Contents for Seagull Models WESTLAND LYSANDER Mk.III 55cc

Page 1 A S S E M B L Y M A N U A L WESTLAND LYSANDER Mk.III 55cc “ Graphics and speciications may change without notice “ . Code : SEA216 Speciications: Wingspan---------------118 in (299.7 cm). Wing area---------------1471 sq.in (94.9 sq.dm). Weight-------------------22 lbs (10 kg).
Page 2 Westland Lysander Instruction Manual. INTRODUCTION. Westland Lysander West- hank you for choosing the ARF by SG MODELS . he land Lysander was designed with the intermediate/advanced sport lyer in mind. It is a semi scale airplane which is easy to ly and quick to assemble. he airframe is conventionally built using balsa, plywood to make it stronger than the average ARF, yet the design allows the aeroplane to be kept light.
Page 3: Kit Contents
INSTALL THE AILERONS KIT CONTENTS. CONTROL HORN. SEA216 Westland Lysander MK III 55cc SEA21601 Fuselage SEA21602 Wing set SEA21603 Tail set SEA21604 Canopy SEA21605 Pilot SEA21606 Cowling Fiberglass control horn SEA21607 Wing struts SEA21608 Wheel pants Epoxy. ADDITIONAL ITEMS REQUIRED. �...
Page 4: Installing The Fuselage Servos
Westland Lysander Instruction Manual. INSTALL ELEVATOR CONTROL HORN. Epoxy. Fiberglass control horn Rudder iberglass control horn. INSTALLING THE FUSELAGE SERVOS. Because the size of servos difer, you may need to adjust the size of the precut Epoxy. opening in the mount. he notch in the sides of the mount allow the servo lead to pass through.
Page 5: Installing The Stopper Assembly
THROTTLE SERVO ARM INSTALLATION. Install adjustable servo connector in the servo arm as same as picture below: Loctite secure. Adjustable servo Switch. connector. INSTALLING THE ENGINE SWITCH. Servo arm. Trim and cut. hrottle servo arm. INSTALLING THE RECEIVER SWITCH. Install the switch into the precut hole in the side, in the fuselage.
Page 6: Fuel Tank Installation
Westland Lysander Instruction Manual. 5) With the stopper assembly in place, the weighted pick-up should rest away from the rear of the tank and move freely inside the tank. he top of the vent tube should rest just below the top of the tank. It should not touch the top of the tank.
Page 7: Mounting The Engine
Blow through one of the lines to ensure the fuel lines have not become kinked inside the fuel tank compartment. Air should low through easily. C/A glue. MOUNTING THE ENGINE . Please see below pictures. Balsa wood. Vent tube. Fuel ill tube. Fuel pick up tube.
Page 8 Westland Lysander Instruction Manual. COWLING. Please see these below pictures. Reinstall the servo horn by sliding the connector over the pushrod wire. Center the throttle stick and trim and install the servo horn perpendicular to the servo center line. Move the throttle stick to the closed po- sition and move the carburetor to closed.
Page 9 3x10mm. 1) Slide the iberglass cowl over the en- 3) Install the muler and muler extension gine and line up the back edge of the cowl onto the engine and make the cutout in the with the marks you made on the fuselage cowl for muler clearance.
Page 10 Westland Lysander Instruction Manual. ELECTRIC POWER CONVERSION. 1) Locate the items necessary to installl the electric power conversion included with your model. M5x35mm. 2) Recommend the items necessary to in- stall the electric power conversion parts included with your model. - Motor: 3 6 0 - Propeller: 24 x10 ~ 25x12 - ESC: 160A- 200A...
Page 11: Installing The Spinner
Blind nut. 4) Attach the motor to the front of the electric motor box using four 4mm blind nut, four M4x20mm hex head bolts to se- cure the motor. Please see picture shown. M4x20mm. INSTALLING THE SPINNER. he propeller should not touch any part of the spinner cone.
Page 12: Installing The Aileron Servos
Westland Lysander Instruction Manual. 2) Place the servo between the mounting blocks and space it from the hatch. Use a pencil to mark the mounting hole loca- tions on the blocks. INSTALLING THE AILERON SERVOS. 3) Use drill bit in a pin vise to drill the mouting holes in the blocks.
Page 13 6) Secure the servo to the aileron hatch using Phillips screwdriver and the screws provided with the servo. 7) Apply 1-2 drops of thin C/A to each of the mounting tabs. Allow the C/A to cure without using accelerator. C/A glue. 8) A string has been provided in the wing to pull the aileron lead through to the wing root.
Page 14: Installing The Rudder Servo
Westland Lysander Instruction Manual. FLAP PUSHROD INSTALLATION. 50mm INSTALLING THE FLAP SERVOS. INSTALLING THE RUDDER SERVO. he process as aileron servo to install ser- vos for rudder. AILERON PUSHROD INSTALLATION. 60mm M3 clevis. M3 lock nut. 2x10mm. Metal clevis. Hex nut. Fuel tubing.
Page 15: Installing The Elevator Servo
INSTALLING THE ELEVATOR SERVO. Please see below pictures. WHEELS AND WHEEL PANTS. Please see these below pictures.
Page 16 Westland Lysander Instruction Manual. Collar. Collar.
Page 17 Epoxy 4x10mm...
Page 18: Installing The Main Landing Gear
Westland Lysander Instruction Manual. INSTALLING THE MAIN LANDING GEAR.
Page 19 INSTALLING RUDDER HINGE. he rudder hinge assembly as below pic- tures. 4x25mm.
Page 20: Installing Horizontal Stabilizer
Westland Lysander Instruction Manual. 3x12mm. INSTALLING HORIZONTAL STABILIZER. Vertical Stabilizer. Horizontal 90º Stabilizer. ELEVATOR PUSHROD INSTALLATION. 1) Locate items necessary to install elevator pushrod. 2) Install the elevator control horn using the same method as with the aileron con- trol horns. 3) Position the elevator control horn on the both side of elevator.
Page 21: Rudder Pushrod Installation
RUDDER PUSHROD INSTALLATION. Locate items necessaryto install rudder pushrod. 115mm. Elevator control horn. 3) hread one clevis and M3 lock nut on M3 lock nut. M3 clevis. to each elevator control rod. hread the horns on until they are lush with the ends of the control rods.
Page 22 Westland Lysander Instruction Manual. Crimp. M3 clevis. Metal connector. Cable end.
Page 23 3) Position the pilot igure on the canopy loor as show. Locate the oval shaped on the canopy loor and remove the cover- ing. Use epoxy to glue this into the base of the pilot igure and glue the cockpit panel in place with C/A glue, please see pictures as shown.
Page 24 Westland Lysander Instruction Manual. INSTALLING BATTERY - RECEIVER. 1) Plug the servos leads and the switch lead into the receiver. Plug the battery pack lead into the switch also. 2) Wrap the receiver and battery pack in the protective foam rubber to protect them from vibration.
Page 25 M4x12mm. Diagonal brace M3x15mm Socket Head Cap Screw Nylon washer Nylon washer M3 locknut Front...
Page 26 Westland Lysander Instruction Manual. ATTACHMENT WING- FUSELAGE. M4x20mm. Attach the aluminum tube into fuselage. Wing tube. Insert two wing panels as pictures below.
Page 27 M4x15mm. M4x12mm.
Page 28: Apply The Decals
Westland Lysander Instruction Manual. APPLY THE DECALS. 1) If all the decals are precut and ready to stick. Please be certain the model is clean and free from oily ingerprints and dust. Position decal on the model where de- sired, using the photos on the box and aid in their location.
Page 30: Flight Preparation
Westland Lysander Instruction Manual. FLIGHT PREPARATION. PREFLIGHT CHECK. 1) Completely charge your trans- Check the operation and direction mitter and receiver batteries before of the elevator, rudder, ailerons and your irst day of lying. throttle. 2) Check every bolt and every glue A) Plug in your radio system per the manufacturer’s instructions and turn Westland Lysander...
