Installing The Spinner - Seagull Models 540 Assembly Manual

EDGE 540.
1.5mm wire
(needle valve).
3) Slide the cowl back over the engine
and secure it in place using six 3mm x 10mm
wood screws. See picture below.
4) Install the muffler and muffler extension
onto the engine and make the cutout in the
cowl for muffler clearance. Connect the fuel
and pressure lines to the carburetor, muffler
and fuel filler valve.
Instruction Manual.
3mm X 10mm
(6pcs).

INSTALLING THE SPINNER.

1) Install the spinner backplate, propeller
and spinner cone. The spinner cone is held in
place using two 3mm x 15mm wood screws.
(spinner is not included).
The propeller should not touch any
part of the spinner cone. If it does,
use a sharp modeling knife and carefully
trim away the spinner cone where the pro-
peller comes in contact with it.
15
