12
SET MODE
■ Others set mode
RS–232C Function
Select [RS-232C] connector output data format from
CI-V and Decode.
Decode Baud Rate
Selects data transmission speed (Baud rate) when
"Decode" is selected in "RS-232C Function" above;
settings are 300, 1200, 4800, 9600 and 19200 bps.
(default: 9600)
Keyboard Type
Selects the connected keyboard type from Japa-
nese, English, United Kingdom, French, French (Ca-
nadian), German, Portuguese, Portuguese (Brazil-
ian), Spanish, Spanish (Latin American) and Italian.
(default: English)
Keyboard Repeat Delay
S e t s t h e t i m e p e r i o d fo r d e l ay f r o m 1 0 0 t o
1000 msec. in 50 msec. steps. (default: 250 msec.)
When a key of the connected keyboard is pushed
and held for the set period, the character is input
continuously.
Keyboard Repeat Rate
Sets the repeating rate for the connected keyboard
within 2.0 to 30.0 cps. (default: 10.9 cps)
When a key of the connected keyboard is pushed
and held, the character is repeatedly input with the
set speed.
IP Address (Valid after Reboot)
Sets IP address for the IC-7700 when connecting to
your PC or LAN (Local Area Network) through the
Ethernet connector.
Subnet Mask (Valid after Reboot)
Sets subnet mask for the IC-7700 when connecting
to your PC or LAN (Local Area Network) through the
Ethernet connector.
(continued)
*cps=character per second
CI–V
• CI-V : Outputs data in CI-V format. (default)
• Decode : Outputs decoded contents in ASCII code
format.
9600
English
250ms
10.9cps
• Available repeating rate
2.0, 2.1, 2.3, 2.5, 2.7, 3.0, 3.3, 3.7, 4.0, 4.3, 4.6, 5.0,
5.5, 6.0, 6.7, 7.5, 8.0, 8.6, 9.2, 10.0, 10.9, 12.0,
13.3, 15.0, 16.0, 17.1, 18.5, 20.0, 21.8, 24.0, 26.7,
30.0
192. 168.
Turn the transceiver power OFF then ON to make
the setting effective. See p. 16-7 for details.
255. 255. 255.
Turn the transceiver power OFF then ON to make
the setting effective. See p. 16-7 for details.
12-18
0. 1
0 (24bit)
