u MICROPHONE CONNECTOR [MIC]
Accepts an optional microphone.
• See p. 15-4 for appropriate microphones.
• See p. 2-10 for microphone connector information.
i MIC GAIN CONTROL [MIC] (p. 3-12)
Adjusts microphone input gain.
• The transmit audio tone in the SSB, AM and FM modes
can be adjusted independently in set mode. (p. 12-5)
✔ How to set the microphone gain.
Set the [MIC] control so that the ALC meter occasionally
moves up-scale during normal voice transmission, in the
SSB, AM or FM mode.
Recommended level for
an Icom microphone
Increases
Decreases
Decreases
o VOX SWITCH
VOX
➥ Push to turn the VOX function ON or OFF dur-
ing SSB, AM and FM mode operation. (p. 6-2)
➥ Push and hold for 1 sec. to enter VOX set mode.
(p. 6-2)
✔ What is the VOX function?
The VOX function (voice operated transmission) acti-
vates transmission without pushing the transmit switch
or PTT switch when you speak into the microphone; then
automatically returns to receive when you stop speaking.
!0 RF POWER CONTROL [RF PWR] (p. 3-12)
Continuously varies the RF output power from a
minimum of 5 W* to a maximum
*AM mode: 5 W to 50 W
Decreases
!1 BREAK-IN SWITCH
Push to turn the break-in function ON
break-in, full-break-in)
eration. (p. 6-3)
✔ What is the break-in function?
The break-in function switches transmit and receive with
CW keying. Full break-in (QSK) can monitor the receive
signal between CW dots and dashes.
Increases
of 200 W*
.
Increases
BK-IN
or OFF during CW mode op-
!2 ELECTRONIC CW KEYER SPEED CONTROL
[KEY SPEED] (p. 4-4)
Adjusts keying speed for the internal electronic CW
keyer.
• 6 wpm (min.) to 48 wpm (max.) is the adjustable range.
!3 MONITOR SWITCH
Monitors your transmitted IF signal.
• The CW sidetone functions regardless of
switch setting in the CW mode.
• The [MONITOR] indicator above this switch lights
green while the function is activated.
!4 BREAK-IN DELAY CONTROL [DELAY] (p. 6-3)
Adjusts the transmit-to-receive switching delay
time for CW semi-break-in operations.
Short delay for
high speed keying
!5 AGC CONTROL [AGC] (p. 5-11)
Adjusts the continuously-variable AGC circuit time
constant.
• To use [AGC] control, push
cator lights).
!6 SQUELCH CONTROL [SQL]
(outer control; p. 3-9)
Adjusts the squelch threshold level. The squelch
mutes noise output from the speaker (closed con-
dition) when no signal is received.
• The squelch is particularly effective for FM. It is also
(semi-
available in other modes.
• The 11 to 12 o'clock position is recommended for the
most effective use of the [SQL] control.
