Icom IC-7700 Instruction Manual page 164

12
SET MODE
■ Display set mode
Meter Response
Set meter needle response between SLOW, MID
and FAST. (default: MID)
Meter Type (Normal Screen)
Selects the desired S/RF meter type during normal
screen display from Standard, Edgewise and Bar.
(default: Standard)
Meter Type (Wide Screen)
Selects the desired S/RF meter type during wide
screen or mini scope display from Edgewise and Bar.
(default: Bar)
Meter Peak Hold (Bar)
Turns the meter peak hold function ON or OFF.
(default: ON)
This function is used for the bar meter only.
Memory Name
Sets the memory name display, during memory
mode operation, ON or OFF. (default: ON)
APF–Width Popup (APF OFF ON)
Enables the pop-up display capability for the APF fil-
ter width when the APF filter is turned ON.
(default: ON)
MN–Q Popup (MN OFF ON)
Enables the pop-up display capability for the notch
filter width when the manual notch filter is turned ON.
(default: ON)
(continued)
12-10
MID
This setting is effective for the standard and edge-
wise meter type selections only.
Standard
Bar
ON
ON
• ON : The programmed memory name is displayed
above the frequency display.
• OFF : No memory name is displayed even a mem-
ory name is programmed.
ON
ON
