■ Others set mode
External Keypad (PSK)
Sets the external keypad for PSK memory transmis-
sion capability ON or OFF.
Only PSK memory channels PT1, PT2, PT3 and PT4
can be transmitted using the external keypad.
See page 2-7 for the equivalent circuit of an external
keypad and connection.
Keyboard [F1]–[F4] (VOICE)
Sets the voice message transmission capability when
one of the [F1] to [F4] keys of the connected key-
board is pushed, to ON or OFF.
Keyboard [F1]–[F4] (KEYER)
Sets the keyer memory transmission capability when
one of the [F1] to [F4] keys is pushed, to ON or OFF.
CI–V Baud Rate
Sets the CI-V data transfer rate. 300, 1200, 4800,
9600, 19200 bps and "Auto" are available. (default:
Auto)
CI–V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7700's address is 74h.
CI–V Transceive
Transceive operation is possible with the IC-7700 con-
nected to other Icom HF transceivers or receivers.
(continued)
12-17
OFF
• ON : In the PSK mode, and while the PSK decode
screen is active, pushing one of the external
keypad switches transmits the desired PSK
memory contents.
• OFF: The external keypad does not function.
(default)
OFF
• ON : Pushing one of the [F1] to [F4] keys transmits
the desired voice message contents during
phone mode operation.
• OFF : [F1] to [F4] keys do not function. (default)
OFF
• ON : Pushing one of the [F1] to [F4] keys transmits
the desired keyer memory contents during
CW mode operation.
And while pushing the [SHIFT] key, push [F1]
to [F4] keys to transmit the desired keyer
memory contents repeatedly.
• OFF : [F1] to [F4] keys do not function. (default)
Auto
When "Auto" is selected, the baud rate is automati-
cally set according to the data rate of connected
controller.
74h
When 2 or more IC-7700's are connected to an op-
tional CT-17 -
ci v level converter
dial to select a different address for each IC-7700;
the range is 01h to DFh.
ON
When "ON" is selected, changing the frequency,
operating mode, etc. on the IC-7700 automatically
changes those of connected transceivers (or receiv-
ers) and vice versa.
12
SET MODE
, rotate the main
