Figure 4 shows the front panel LEDs.
Figure 4 Front Panel LEDs on the Server Blade
UID LED
1
Server health LED
2
Internal health LED
3
Table 5 details the functions of the front panel LEDs.
Table 5 BL860c Server Blade Front Panel
Item
1
2
3
4
5
6
7

SAS Disk Drive LEDs

There are two SAS disk drives on the server blade. They have identical LEDs that show the drive
status.
Figure 5 shows the locations of the SAS disk drive LEDs.
NIC 1 LED
4
NIC 2 LED
5
LED Description
Unit identification (UID)
Server health
Internal health
NIC 1
NIC 2
NIC 3
NIC 4
NIC 3 LED
6
NIC 4 LED
7
Controls, Ports, and LEDs 21
