Synchronize Array
To synchronize the IM array, press Enter on Synchronize Array. The screen prompts you to perform
this action. Press Y for yes or N for no. This field is grayed out under the following conditions:
The array is inactive.
The array does not need to be resynchronized.
The adapter's MPT firmware does not support the feature
Non-IR firmware is used.
IR is disabled. The array is inactive.
Activate Array
To activate an IM array, press Enter for Activate Array. You are prompted to perform this action.
Press Y for yes or N for no.
Delete Array
To delete an IM array, press Enter for Delete Array. You are prompted to perform this action. Press
Y for yes, and N for no.
The following are descriptions for the Delete Array screen
Identifier
Type
Scan Order
Size (MB)
Status

Exit the SAS Configuration Utility Screen

Because some changes only take effect when you exit the utility, exit the utility properly. To exit
the utility:
1. To return to the Adapter List from Adapter Properties, press ESC.
2. To exit the utility from the Adapter List, press ESC.
A similar exit screen is used when exiting most other screens, and can be used to save settings.
The exit screen shows some options that are grey, indicating they are not available. You can only
select available options. The exit choices are as follows:
Are you sure you want to exit?
Cancel Exit
Save changes and reboot
Discard changes and reboot
Exit the Configuration Utility and Reboot

CFGGEN Utility

The cfggen utility is a command line utility that runs in the Linux, EFI, and Windows Pre-Installation
(WinPE) environments. It is a minimally interactive program that you run from a command line
prompt, or a shell script.
The results from invoking this utility are communicated through the program status value that is
returned when the program exits.
Use the cfggen utility to create IM storage configurations on SAS controllers. Some cfggen
commands work only with SAS adapters in the EFI environment.
Displays the identifier of this array.
Displays the RAID type.
Displays the scan order of the array.
Displays the size of this array.
Displays the status of this array.
Configuring the HP 2 Internal Port SAS Host Bus Adapter 61
