2.2.2 Installation Options

This section shows various installation options for the V2 Speaker.
2.2.2.1 V2 Speaker with an External Device
In Figure
programmed to drive an external device such as an alert strobe. This external device may also be
addressed from a separate Unified Communication (UC) server.
Alert Strobe
External Device
Such as an
Electric Door Strike
or Strobe Light
AC or DC
Power Source
as Required by
an External Device
Operations Guide
2-4, when the V2 Speaker is called from a remote phone, the relay on the speaker can be
Figure 2-4. V2 Speaker with Alert Strobe
Speaker
AUX POWER (-)
Output Contacts
AC or DC-rated
Depending Upon
External Device
Requirements
930274I
AUX POWER (+)
(+12VDC @ 1A)
RELAY COM
RELAY NO
+5V OUT
J10
Installing the VoIP V2 Speaker
Device Configuration
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT (-)
LINE OUT (+)
J9
CyberData Corporation
12
