2.2.2.3 V2 Speaker with Line Out
In Figure
to an auxiliary amplifier to drive additional horns or speakers. This is done through the line-out
connection.
AUX POWER (+)
(+12VDC @ 1A)
AUX POWER (-)
RELAY COM
RELAY NO
+5V OUT
Operations Guide
2-7, for areas that require more speaker volume, the V2 Speaker can be connected directly
Figure 2-7. V2 Speaker with Line Out
Speaker
Office area in Factory
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT (-)
LINE OUT (+)
J9
J10
Line Out:
Output Signal Amplitudes 2.0 VPP maximum
Output Level +2dBm nominal
Total Harmonic Distortion 0.5% maximum
Output Impedance 10k ohm
