2.2.2 Installation Options

Figure 2-7
2.2.2.1 V2 Speaker with Remote Call Button
In Figure
determined extension.
When you call the Speaker from a remote phone and auto-answer is not enabled, the LED on the
remote button will blink. The call will be answered when the button is pressed.
Speaker
4 wire interface up to 25 feet
POWER IN +
(+12VDC 500mA)
POWER GND
RELAY COM
RELAY NO
+5 VDC
BUTTON-SENSE
Operations Guide
through Figure 2-10 illustrates various installation options for the V2 Speaker.
2-7, when you press the remote call button, the speaker will initiate a SIP call to a pre-
Figure 2-7. V2 Speaker with Remote Call Button
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT GND
LINE OUT (+)
BUTTON LED (-)
J9
J10
930274C
Installing the VoIP V2 Speaker
Device Configuration
BS
+5
GND
LED
Remote Mounted Call
Button with LED Indicator
CD Part Number 011073
