2.2.5 Installation Options

Figure 2-5
Speaker.
2.2.6 Singlewire-enabled Speaker with Remote Call Button
In Figure
determined extension.
When you call the Speaker from a remote phone and auto-answer is not enabled, the LED on the
remote button will blink. The call will be answered when the button is pressed.
Speaker
AUX POWER (+)
(+12VDC @ 1A)
AUX POWER (-)
RELAY COM
RELAY NO
BUTTON LED (+)
BTN SENSE
Operations Guide
through Figure 2-6 illustrates various installation options for the Singlewire-enabled
2-4, when you press the remote call button, the speaker will initiate a SIP call to a pre-
Figure 2-4. Singlewire-enabled Speaker with Remote Call Button
AUX SPEAKER (-)
AUX SPEAKER (+)
BTN SENSE GND
LINE OUT (-)
LINE OUT (+)
BUTTON LED (-)
J9
J10
930463C
Installing the Singlewire-enabled Speaker
Set Up and Test the Speaker
Back View
CyberData Corporation
25
