FEATURES AND FUNCTIONS

1.
Green LED- traffic indicator- illuminates when there is communication between the local and remote units.
2.
Yellow LED- power indicator- illuminates when power has been supplied to the unit
3.
Cat 5- RJ45 female- for connecting the CAT 5 cable
4a. Video Connector- 15HD female- for connecting the local user's VGA monitor
4b. S-Video Connector- 4 pin miniDIN female- for connecting the local user's S-video display (S-Video models
only)
5a. RS232 Connector- 9D male- for connecting the local user's touchscreen monitor (models with RS232
support only)
5b. Audio Jack- 3.5mm stereo audio jack- for connecting to local speakers (models with audio support only)
6. Mouse Connector- green female 6 miniDIN- for connecting the local user's mouse
7.
Keyboard Connector- purple female 6 miniDIN- for connecting the local user's keyboard
FEATURES AND FUNCTIONS
5a
6
7
-
NTI
R
Network Technologies Inc
XTENDEX
(Front View)
ST-C5KVMRS-600 Local Unit
5b
6
7
-
NTI
R
Network Technologies Inc
XTENDEX
(Front View)
ST-C5KVMA-600 Local Unit
5b
-
NTI
R
Network Technologies Inc
XTENDEX
(Front View)
ST-C5SVA-600 Local Unit
1
2
3
15
+
- +
3
15
+
- +
3
15
+
- +
3
4a
XTENDEX
Inc Technologies NTI Network
R
(Rear View)
4a
XTENDEX
Inc Technologies Network
NTI
R
(Rear View)
4b
XTENDEX
Inc Technologies NTI Network
R
(Rear View)
