INTRODUCTION

The XTENDEX Series CAT5 Extender (XTENDEX) is designed to enable one CPU to be controlled by two users, one local and
one remote. The remote user can be located as much as 600 feet away from a PS/2 CPU via Category 5 unshielded twisted-
pair cable. The local user will be located near the CPU.
The XTENDEX Series Extender is extremely simple to install and has been thoroughly tested to insure reliable performance.
Through the use of Category 5 cable it is possible to economically increase the flexibility of a computer system. Here are some of
the features and ways this can benefit any workplace:
• Allows the placement of computer peripherals (monitor, keyboard, and mouse) in a location where
only these parts are needed without having the CPU there too, taking up valuable space
• Allows a PS/2 CPU to be accessed by both a local and remote user (up to 600 feet away)
• Compatible with XGA, VGA, and SVGA systems
• Provides crisp and clear resolution up to 1024 x 768 @ 600 feet (see page 8 for more details)
• Compatible with all NTI switches and splitters, enabling the joining of products to create a system that
satisfies all networking needs
• Video quality adjustment, for varying lengths of cable, is automatic (most models, see below and
page 13) providing optimum image quality
• Audio frequency response is 20Hz to 20Khz, + 1Db (models with audio support only)
• Digital transmission of audio signals reduces any loss in quality (models with audio support only)
This manual covers each of the XTENDEX Series CAT5-600 Extender models offered. Some features described in this manual
are available in some models and not in others. The chart below shows the features supported in each:
Model
ST-C5KVM-600
ST-C5KVMA-600

ST-C5KVMRS-600

ST-C5V-600

ST-C5VA-600

ST-C5VRS-600

ST-C5SV-600

ST-C5SVA-600
ST-C5KVMRS-600-SC5
Video Keyboard Mouse
Support
VGA Yes
VGA Yes
VGA Yes
VGA No
VGA No
VGA No
S-Video No
S-Video No
VGA Yes
Audio RS232
Support Support
No No
Yes No
No Yes
No No
Yes No
No Yes
No No
Yes (RCA) No
No Yes
1
Video Quality
Adjustment
Automatic
Automatic
Automatic
Manual
Automatic
Automatic
Manual
Automatic
Manual
