- Page 1 ® XTENDEX Series ST-C5HDA-600 ST-C5HDTV-600 EXTENDERS Installation and Operation Manual ST-C5HDA-600 HD Video/Digital Audio Extender MAN079 Rev Date 4/13/2007...
- Page 2 CE Statement We, Network Technologies Inc, declare under our sole responsibility that the ST-C5HDA-600 and ST-C5HDTV-600 are in conformity with European Standard EN55022. Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Features and Functions..............................3 Limitations ..................................5 Preparation for Installation .............................. 5 Installation ..................................6 Installing The Local Unit .............................. 6 Connect The CAT5 Cable............................7 Installing The Remote Unit ............................8 Connect the CAT5 cable.............................. -
Page 4: Introduction
NTI EXTENDEX Extenders INTRODUCTION The XTENDEX Series ST-C5HDA-600 CAT5 Extender (XTENDEX) is designed to enable the signals from one high-definition (HD) video and digital (coax / SPDIF) audio source to be seen and heard through two high-definition televisions (HDTV) and digital audio devices, one of each local and one of each remote. -
Page 5: Materials
Note: CAT5/5e/6 shielded twisted-pair cable(s) must be used to meet CE emission and immunity requirements. Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com and we will be happy to be of assistance. -
Page 6: Features And Functions
NTI EXTENDEX Extenders N T I N e t w o r k T e c h n o l o g i e s I n c X T E N D E X ( F r o n t V i e w ) - Page 7 NTI EXTENDEX Extenders Cat 5- RJ45 female- for connecting the CAT 5 cable Yellow LED- traffic indicator- illuminates when there is traffic between the local and remote units Green LED- power indicator- illuminates when power has been supplied to the unit 9VDC- 1.0A- connection jack for the AC adapter...
-
Page 8: Limitations
Secure cables as needed to minimize this. Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings. WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty. -
Page 9: Installation
NTI EXTENDEX Extenders INSTALLATION Installing The Local Unit 1. Plug the cables of the Local Unit into the audio/video source. (See Fig. 1) as per the chart below. Connector Connect to Color "Pr" on video source Blue "Pb" on video source Green "Y"... -
Page 10: Connect The Cat5 Cable
Connect 75 ohm RCA cables between the local HDTV and the RCA connectors marked "Y", "Pb", and "Pr" on the local unit as shown in Fig. 2. Connect coax cable for digital audio (ST-C5HDA-600 only) or stereo audio cable (ST-C5HDTV-600 only) between the audio connection(s) and the audio device. See Fig. 2. -
Page 11: Installing The Remote Unit
Connect 75 ohm RCA cables between the remote HDTV and the RCA connectors marked "Y", "Pb", and "Pr" on the Remote Unit as shown in Fig. 2. Connect coax cable for digital audio (ST-C5HDA-600 only) or stereo audio cable (ST-C5HDTV-600 only) between the audio connection(s) on the Remote Unit and the audio device. See Fig. 2. -
Page 12: Plug-In And Power Up
NTI EXTENDEX Extenders Plug-in and Power Up Plug the power cords from the HD television, audio/video source, and speakers (if applicable) into power outlets if this has not already been done. Connect each AC adapter power connector to the 9VDC ports on the Remote and Local Units Plug each AC adapter into a power outlet. -
Page 13: Technical Specifications
Brown Figure 7- View looking into RJ45 female Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings. WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty. -
Page 14: Troubleshooting
NTI EXTENDEX Extenders TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
