  • Page 1 VideoJet 8000 User Guide...

  • Page 2: Contents

    Copyright This user guide is the intellectual property of VCS and is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose, by whatever means, electronic or mechanical, without the express written permission of VCS.

  • Page 3: Table Of Contents

    Function test ........111 VideoJet 8000...
  • Page 4 MPEG viewer installation ......123 Hardware connections between VCS units ....124 Establishing the connection.

  • Page 5: Chapter 1 Preface

    Preface This user guide is intended for persons responsible for the installation and operation of VideoJet 8000. International, national and any regional regulations regarding electronics must be followed at all times. The user manual describes the installation and operation of the unit.

  • Page 6: Intended Use

    The VideoJet 8000 network video server transmits video and control signals over data networks (such as Ethernet LANs and the Internet). The integrated hard drive enables the VideoJet 8000 to be used as a DVR. It is designed for use in CCTV systems. By incorporating external alarm devices, various functions can be triggered automatically.

  • Page 7: Chapter 2 Safety Information

    – if the unit has been exposed to rain or moisture, – if foreign matter has infiltrated the unit, – after long storage under adverse conditions or – after exposure to extraordinary transport stress. In such cases, have the unit checked by VCS. VideoJet 8000...

  • Page 8: Installation And Operation

    Actions beyond these may lead to personal injuries, property damage or damage to the equipment. Maintenance and repair Never open the casing of the VideoJet 8000 yourself, there are no user serviceable parts inside. Ensure that all maintenance or repair work is performed only by qualified personnel (electrical technicians).

  • Page 9: Chapter 3 Product Description

    Mounting kit for installation in 19" racks The quick start guide “First Steps” in English and German VCS product CD with the following content: – The quick start guide “First Steps” in English and German – User guide in English and German –...

  • Page 10: Configuration Requirements

    Microsoft Internet Explorer (version 5.5 or later) or decoder software, such as VIDOS from VCS MPEG-2 capable hardware decoder from VCS (such as VIP 1000) as a receiver and a connected video monitor Note Make sure the graphic card for receiving on the computer monitor is set to 16 or 32 bit color depth and the Microsoft Virtual Machine is installed on the computer.

  • Page 11: Overview Of Functions

    The supplied mounting kit makes installation in a 19" rack fast and easy. Two units, a VideoJet 8000 as the transmitter and a VIP 1000 as the receiver, can form a stand-alone system for data transfer without a PC. The system can be expanded to include additional transmitters and receivers so that video images from one transmitter can be received simultaneously on a number of receivers.
  • Page 12 Snapshots Individual video frames (snapshots) can be called up in JPEG format by the VideoJet 8000, stored on the computer hard drive or be displayed in a separate browser window. Backup Video sequences can be saved to the computer's hard drive from either the live video page or the local hard drive mode with just a mouse-click.
  • Page 13 Chapter 3 Product Description Summary The main functions of the VideoJet 8000 can be summarized as follows: Video and data transmission over IP data networks Multicast function for simultaneous picture transmission to multiple receivers 8 independent, analog BNC video inputs FBAS (PAL/NTSC)

  • Page 14: Rear Panel Connectors

    RJ45 jack for transmitting control data (RS232, RS422 and RS485 protocols) and for configuration with terminal software 5 RJ45 jack for ISDN for future functional extensions 6 RJ45 jack 10/100/1000 MBit Base-T for connecting to an Ethernet LAN 7 Power receptacle for connecting the power cable VideoJet 8000...

  • Page 15: Front Panel

    14 Set button for saving changes to the operating parameters (for future functional extensions) 15 Arrow keys for navigation in the configuration menu Further information on the LEDs can be found on page 135. VideoJet 8000...
  • Page 16 Product Description Chapter 3 VideoJet 8000...

  • Page 17: Chapter 4 Installation

    Installation The VideoJet 8000 is designed for tabletop operation and installation in control cabinets. The supplied mounting kit makes installation in a 19" rack fast and easy. Four self-adhesive, anti-slip rubber feet are included with delivery. These can be attached to the bottom of the unit.

  • Page 18: Control Cabinet Installation

    Installation Chapter 4 Control cabinet installation The VideoJet 8000 is ready for installation in a 19" rack. The necessary mounting kit is included with the delivery. Warning! When installing in cabinets, ensure that each unit has adequate ventilation. The free space around the unit must be at least 5 cm on the right and left sides and at least 10 cm in the back.
  • Page 19 Chapter 4 Installation Installation overview VideoJet 8000...

  • Page 20: Connections

    Cameras Up to 8 standard video sources (CCTV cameras) can be connected to the VideoJet 8000. Any cameras or other video sources that produce a standard PAL or NTSC signal are suitable for connection. – Connect each of the cameras or other video sources with a video cable (75 ohm) to the BNC jacks Video 1 to Video 8.
  • Page 21 RxD (receive data) RxD+ (receive data plus) CTS (clear to send) RxD- (receive data minus) – – – – GND (ground) GND (ground) – – TxD (transmit data) TxD- (transmit data minus) RTS (ready to send) TxD+ (transmit data plus) VideoJet 8000...

  • Page 22: Switching On/Off

    VideoJet 8000 to the mains supply after all other connections have been established. The VideoJet 8000 has no power switch. When the unit is connected to power, it is ready for operation after startup. – Attach the connector of the power cable to the Power socket.

  • Page 23: Setup Using A Terminal Program

    Setup using a terminal program Data terminal A data terminal may be connected to the VideoJet 8000 for setup and local control. The data terminal usually consists of a computer with suitable terminal software. A serial cable is provided with the delivery for making the connection.
  • Page 24 Enter key to send the data to the VideoJet 8000. Assigning an IP address To operate the VideoJet 8000 on a network, an IP address valid for the network must be provided. The following default address has been pre-set at the factory: 192.168.0.1 Note The new addresses will only be in effect after restarting.
  • Page 25 Chapter 4 Installation Additional parameters Using the terminal program, you can check other basic parameters and modify them where necessary. Use the on-screen commands displayed in the various submenus for this purpose. VideoJet 8000...
  • Page 26 Installation Chapter 4 VideoJet 8000...

  • Page 27: Chapter 5 Configuration Using A Web Browser

    In order for the computer to decode live video images, the special ActiveX control must be installed. The latest version of the ActiveX control can be obtained from VCS customer service or from the download pages on the Internet site at www.vcs.com.
  • Page 28 The following default address has been pre-set at the factory: 192.168.0.1 – Start the Web browser. – Enter the IP address of the VideoJet 8000 as the URL. The connection will be established, and after a short time the Livepage with the video image will appear.

  • Page 29: Choosing The Configuration Mode

    Installation Wizard, the overview and expert mode. All settings are stored in the VideoJet 8000 memory, and they are preserved even if the power is interrupted. Installation Wizard The installation wizard is recommended for initial setup of the unit. It takes you step by step through the necessary settings.
  • Page 30 (such as software updates) can only be performed in expert mode. Beginning configuration Click the Settings link in the top part of the Livepage. A new page will be opened, and the required installation mode can be selected on the menu line: VideoJet 8000...

  • Page 31: Installation Wizard

    Chapter 5 Configuration using a Web Browser Installation Wizard The VideoJet 8000 Installation Wizard guides you step by step through the necessary settings. Starting the Installation Wizard The Installation Wizard can be started by clicking the Settings link on the Livepage.
  • Page 32 Clicking Cancel causes the original settings to remain unchanged. Warning! Always continue with the Installation Wizard until the last page is reached. Only there is it possible to save the changes by clicking Finish. VideoJet 8000...
  • Page 33 – Click Yes to start the Application Wizard. – Click Finish to close the Installation Wizard. The settings will be saved and loaded on the VideoJet 8000, and the Application Wizard will start immediately thereafter. It works similar to the Installation Wizard.

  • Page 34: Device Overview

    The individual configuration parameters are grouped and displayed in separate windows. Opening the overview The graphical overview can be accessed by clicking Settings on the Livepage. – Click the Overview link. The page with the graphical overview will appear. VideoJet 8000...
  • Page 35 Save the changes made in each window by clicking Set. When Set is clicked, only the changes in that particular window are saved. A description of the individual windows that can be accessed via the group graphics of the overview is given below. VideoJet 8000...
  • Page 36 (see page 76). It is also used by VIDOS, the VCS software for administering video monitoring systems. The camera name helps to identify the camera or its location in the program.
  • Page 37 Chapter 5 Configuration using a Web Browser Motion detector The VideoJet 8000 has an integrated video sensor which can detect changes in the signal. Such changes are due primarily to movements in the camera's field of view. The video sensor can be configured separately for each encoder, i.e. for each camera connected.
  • Page 38 – If necessary, click Clear all first to clear the current selection (fields marked red). – Click the fields to be activated. Activated fields are marked red. – Click Select all to select the entire video frame for monitoring. VideoJet 8000...
  • Page 39 This field lists all the motion alarms and the date and time of their occurrence. The events for the currently selected camera input will be listed. After adjusting the settings, the reaction of the VideoJet 8000 can be checked in the preview frame on the right side of the page. Sensor fields that are currently reacting to motion are marked red on the video image.
  • Page 40 Select a controllable device from the list. If you want to use the serial interface to transmit transparent data, select Transparent. Note After selecting a device, the remaining parameters in the window are set automatically and should not be changed. Baud rate: Select the value for the data transmission rate in Bit/s. VideoJet 8000...
  • Page 41 The number of data bits per character cannot be changed. Stop bits: Select the number of stop bits per character. Parity: Select the type of parity check. Interface mode: Select the desired protocol for the serial interface. Half-duplex mode: Choose the setting appropriate for your application. VideoJet 8000...
  • Page 42 Select the option On in order to activate the alarm via the corresponding external alarm sensor. Otherwise, select Off. Alarm input status: You can choose whether the alarm is triggered by an Active high or Active low voltage level. VideoJet 8000...
  • Page 43 The numbering of the encoders corresponds to the labeling of the inputs on the back of the unit. The MPEG-2 data transmission can be configured to suit the environment (for instance, network architecture, bandwidth, etc.). Preconfigured profiles are provided, which reflect different priorities and environments. VideoJet 8000...
  • Page 44 5 MBit/s transmission rate with high image quality 3MBPS low delay 3 MBit/s transmission rate with a low delay for image refresh 4.5MBPS low delay 4.5 MBit/s transmission rate with a low delay for image refresh – Select the desired setting from the list. VideoJet 8000...
  • Page 45 Configuration using a Web Browser Alarm connections You can select a number of options for the response of the VideoJet 8000 to an alarm. In case of an alarm, the VideoJet 8000 can establish a connection to a predefined IP address (VCS hardware receiver or PC with receiver software) automatically.
  • Page 46 Select camera on alarm: Here you can select the camera whose image will automatically be displayed first to the receiver after the alarm connection has been established. Depending on the system configuration, the receiver can then also select the other cameras. VideoJet 8000...
  • Page 47 Configuration using a Web Browser Partition The VideoJet 8000 hard drive can have up to eight partitions configured in the same way as is typical for computer hard drives. Parameters can be defined individually for each partition, such as size, quality, type of video recording and the compression standard used.
  • Page 48 Note More than one partition with the same configuration can be created in a single process. Mark the checkbox Apply same settings for all new partitions on the initial page of the wizard. VideoJet 8000...
  • Page 49 Continue with the Installation Wizard until the last page. Only there is it possible to save the settings by clicking Finish. Settings made with the Installation Wizard only take effect after the Finish button on the last page is clicked. Clicking Cancel causes the original settings to remain unchanged. VideoJet 8000...
  • Page 50 – Make the desired changes. – Click Set to save the changes. – After closing the window, click the Set button in the main window to send the changes to the unit and save them there. VideoJet 8000...
  • Page 51 – Click Delete partition to delete the selected partition. The partition will not be removed from the list. Rather, it remains without a name or size specification in order to give you a better overview. – Click Set to send the changes to the unit and save them. VideoJet 8000...
  • Page 52 Select the partition on which you want to record. Recording of the individual camera inputs is always done on dedicated partitions. Timed recording Here you can specify the times during which continuous recording on the hard drive takes place. VideoJet 8000...
  • Page 53 25 fps (PAL) or 30 fps (NTSC) from a camera to its assigned partition. Other settings result in a lower frame rate and thus require less partition space. This means that the VideoJet 8000 can record for a longer period of time. Post-alarm recording frame rate: If an alarm occurs during a default recording, the frame rate can be changed automatically to the post-alarm rate.
  • Page 54 The display indicates the space currently used on the partition. Free on this partition: The display indicates the current amount of free space on the partition. Recording status: The icon indicates the recording status on this partition. When a recording is being made, the icon is animated. VideoJet 8000...
  • Page 55 If a time period has already been selected for the timed recording, you can no longer select it for alarm recording (see Timed recording, page 52). Warning! For alarm recordings, alarm tracks must be set up on the desired partition (see Number of alarm tracks, page 56). VideoJet 8000...
  • Page 56 Configuration using a Web Browser Chapter 5 The VideoJet 8000 uses a special recording mode for alarm recording to optimize the use of storage capacity. As soon as a time slot begins for the alarm recording, continuous recording starts on a segment the size of a complete alarm sequence (pre- and post-alarm).
  • Page 57 The display indicates the space currently used on the partition. Free on this partition: The display indicates the current amount of free space on the partition. Recording status: The icon indicates the recording status on this partition. When a recording is being made, the icon is animated. VideoJet 8000...
  • Page 58 You should therefore back up all important sequences to the hard drive of the computer before making such changes. Partition name: Here you can enter a new name for the partition if needed. VideoJet 8000...
  • Page 59 Alarm input settings page (see page 42). The video alarm is activated on the Camera settings page (see page 36). Partition total size: The displayed value shows the total space in MB occupied by the partition on the hard drive. VideoJet 8000...
  • Page 60 – Click Start all to activate all the configured partitions and begin the associated recording activities. – Click Stop to deactivate the currently selected partition and terminate its recording activities. – Click Stop all to deactivate all the configured partitions and halt the associated recording activities. VideoJet 8000...
  • Page 61 Chapter 5 Configuration using a Web Browser System settings Various basic configuration data for the VideoJet 8000 can be set or selected here. VideoJet 8000...
  • Page 62 Enter a designation that makes it as easy as possible to identify the location unambiguously. Unit ID: Each VideoJet 8000 should be assigned a unique identifier that can be entered here as an additional means of identification. Web site language: Here you select the language of the user interface.
  • Page 63 VideoJet 8000. Time zone and Time server IP address: The VideoJet 8000 can receive a time signal from a TIME server (NTP server) and use it to set the internal clock. The unit calls up the time signal automatically every two hours.
  • Page 64 Configuration using a Web Browser Chapter 5 Ethernet settings The settings in this dialog are used to integrate the unit into an existing network. The group IP address (multicast address) and the channel (port) must be set separately for each encoder. VideoJet 8000...
  • Page 65 IP address. Internet IP address: Enter the desired IP address for the VideoJet 8000 in this field. The IP address must be valid for the network. Subnet mask: Enter the subnet mask here if the unit is to communicate via a subnet.
  • Page 66 When the multicast address is set to 0.0.0.0, the VideoJet 8000 operates in multi- unicast mode (copies the data streams on the unit). If a valid multicast group IP address is entered for each encoder, the unit operates in the multicast mode (duplication of the data stream on the network).
  • Page 67 Enter the port address for the particular encoder here. Multicast packet TTL: A value can be entered to specify how long the multicast data packets are active on the network. If multicast is to be run over a router the value must be greater than 1. VideoJet 8000...
  • Page 68 Either GIF or JPEG images can be used. The file paths must correspond to the access mode (local paths such as C:\Images\Logo.gif for local files and URLs such as http://www.vcs.com/images/logo.gif for files on the Internet). Please note for access via Internet/intranet that there must be a connection in order to display the image.
  • Page 69 Select this option to save the event log in a text file on the local computer. These logs can be viewed, edited and printed with any software that can work with text files (such as Microsoft Word or Excel). VideoJet 8000...
  • Page 70 If the saving of log files is enabled (for example "Save event minutes on livepage"), these will be stored by default as text files on the Windows Desktop. The path for saving the files can be changed in expert mode (see page 108). VideoJet 8000...

  • Page 71: Expert Mode

    Configuration using a Web Browser Expert Mode Expert Mode allows all parameters of the VideoJet 8000 to be configured. You can view the current settings by opening one of the configuration pages. The settings can be changed by entering new values or by selecting a predefined value from a list field.
  • Page 72 Enter a designation that makes it as easy as possible to identify the location unambiguously. Unit ID: Each VideoJet 8000 should be assigned a unique identifier that can be entered here as an additional means of identification. VideoJet 8000...
  • Page 73 Configuration using a Web Browser Password settings User name: A VideoJet 8000 unit is generally protected by a password to prevent unauthorized access. The VideoJet 8000 uses three levels of authorization: live, service and user. The service authorization level allows you to use all the functions of the VideoJet 8000 and change all the settings after entering the proper password.
  • Page 74 Enter the current date here. It is not necessary to enter the day of week; this is supplied automatically by the internal clock Unit time: Enter the current time here or click the Synchr. PC button to copy the system time from your computer to the VideoJet 8000. VideoJet 8000...
  • Page 75 Configuration using a Web Browser Time server The VideoJet 8000 can receive a time signal from a TIME server (NTP server) and use it to set the internal clock. The device calls up the time signal automatically every two hours.
  • Page 76 The settings on this page apply to all camera inputs. Camera name stamping: This field sets the position of the camera name overlay. It can be displayed on Top or on Bottom of the image or you can define a position yourself via the VideoJet 8000...
  • Page 77 W. A red W indicates that the sequence (live or saved) has been manipulated. Displayed alarm message: Enter the text to be shown in the event of an alarm. It can contain up to 31 characters. VideoJet 8000...
  • Page 78 MPEG-2 encoder configuration The data transmission parameters can be configured to fit the local operating environment (network architecture, bandwidth, data structures, etc.). The VideoJet 8000 has eight preconfigured profiles, which reflect different priorities and environments. Note The settings for the encoders must be configured separately for each camera input.
  • Page 79 5 MBit/s transmission rate with high image quality 3MBPS low delay 3 MBit/s transmission rate with a low delay for image refresh 4.5MBPS low delay 4.5 MBit/s transmission rate with a low delay for image refresh – Select the desired setting from the list. VideoJet 8000...
  • Page 80 Each GOP always begins with an I-frame. Note B-Frames have a large delay and are not suitable for some applications, such as manually controlling a dome camera. Keep this in mind when choosing a GOP structure and length. VideoJet 8000...
  • Page 81 GOP length that is a multiple of two. The "IPBB" structure has length that are multiples of three. The GOP structure I requires no GOP length. Video streaming type: The option VES (Video Elementary Stream) is preset for the video stream. It cannot be changed. VideoJet 8000...
  • Page 82 Video resolution: Select the desired resolution for the MPEG-2 video image. The following resolutions are available: 352 × 288 pixels 704 × 576 pixels Reset parameter for the preset: Click Default to revert the profile to its factory presets. VideoJet 8000...
  • Page 83 Configuration using a Web Browser Partitioning data The VideoJet 8000 hard drive can have up to eight partitions configured in the same way as is typical for computer hard drives. Parameters can be defined individually for each partition, such as size, quality, type of video recording and the compression standard used.
  • Page 84 Mark the checkbox Apply same settings for all new partitions on the initial page of the wizard. – Click Add partition to start the partition wizard. – Always read the information in the upper part of the window first. VideoJet 8000...
  • Page 85 – Click to select the partition in the list that you want to change. – Click Edit partition. The Partition Settings window will appear, showing the information for the selected partition. – Make the desired changes. – Click Set to save the changes. VideoJet 8000...
  • Page 86 – Click Delete partition to delete the selected partition. The partition will not be removed from the list. Rather, it remains without a name or size specification in order to give you a better overview. – Click Set to send the changes to the unit and save them. VideoJet 8000...
  • Page 87 Here you can specify the times during which continuous recording on the hard drive takes place. For each weekday, there are separate selection fields for each partition and thus for each camera input. You can select 16 individual recording periods for each weekday. VideoJet 8000...
  • Page 88 25 fps (PAL) or 30 fps (NTSC) from a camera to its assigned partition. Other settings result in a lower frame rate and thus require less partition space. This means that the VideoJet 8000 can record for a longer period of time. Post-alarm recording frame rate: If an alarm occurs during a default recording, the frame rate can be changed automatically to the post-alarm rate.
  • Page 89 The display indicates the space currently used on the partition. Free on this partition: The display indicates the current amount of free space on the partition. Recording status: The icon indicates the recording status on this partition. When a recording is being made, the icon is animated. VideoJet 8000...
  • Page 90 If a period has already been selected for the timed recording, you can no longer select it for alarm recording (see Timed recording, page 87). Warning! For alarm recordings, alarm tracks must be set up on the desired partition (see Number of alarm tracks, page 91). VideoJet 8000...
  • Page 91 Chapter 5 Configuration using a Web Browser The VideoJet 8000 uses a special recording mode for alarm recording to optimize the use of storage capacity. As soon as a time slot begins for the alarm recording, continuous recording starts on a segment the size of a complete alarm sequence (pre- and post-alarm).
  • Page 92 The display indicates the space currently used on the partition. Free on this partition: The display indicates the current amount of free space on the partition. Recording status: The icon indicates the recording status on this partition. When a recording is being made, the icon is animated. VideoJet 8000...
  • Page 93 You should therefore back up all important sequences to the hard drive of the computer before making such changes. Partition name: Here you can enter a new name for the partition if needed. VideoJet 8000...
  • Page 94 Motion Detector page (see page 98). Alarm inputs and the video alarms are activated on the Alarm sources page (see page 96). Partition total size: The displayed value shows the total space in MB occupied by the partition on the hard drive. VideoJet 8000...
  • Page 95 – Click Start all to activate all the configured partitions and begin the associated recording activities. – Click Stop to deactivate the currently selected partition and terminate its recording activities. – Click Stop all to deactivate all the configured partitions and halt the associated recording activities. VideoJet 8000...
  • Page 96 Configuration using a Web Browser Chapter 5 Alarm sources You can configure the possible alarm triggers for the VideoJet 8000 (such as alarm inputs and video signal monitoring of the camera inputs). Alarm input 1 ... Alarm Input 10: Select the option On in order to activate the alarm via the corresponding external alarm sensor.
  • Page 97 Chapter 5 Configuration using a Web Browser Video loss alarm 1-4 ... Video loss alarm 5-8: Select On if the VideoJet 8000 is to give an alarm when the video signal is interrupted. 1./2. SNMP host address: Enter the IP addresses of up to two chosen receivers here if the alarm message is to be sent via SNMP-traps.
  • Page 98 Motion detector The VideoJet 8000 has an integrated video sensor which can detect changes in the signal. Such changes are due primarily to movements in the camera's field of view.
  • Page 99 If it is necessary to exclude particular regions of the camera's field of view from monitoring due to continuous movement (by a tree in the wind, etc.), the relevant fields can be deactivated. VideoJet 8000...
  • Page 100 – Select the desired value by dragging the scroll thumb to the desired position. Motion alarm status: This field lists all the motion alarms and the date and time of their occurrence. The events for the currently selected camera input will be listed. VideoJet 8000...
  • Page 101 Chapter 5 Configuration using a Web Browser After adjusting the settings, the reaction of the VideoJet 8000 can be checked in the preview frame on the right side of the page. Sensor fields that are currently reacting to motion are marked red on the video image. Inactive sensor fields are marked green.
  • Page 102 – To do this, enter the old IP address in the address field of the Web browser and append /reset to it (e.g. 192.168.0.80/reset). The VideoJet 8000 will be restarted after which it can only be accessed at the new IP address.
  • Page 103 IP address. To connect to the VideoJet 8000 via the Internet, it is enough to enter the unit name and the URL of the DNS server. The server returns the current Internet IP address for the connection.
  • Page 104 Multicast configuration In addition to a 1:1 connection between an encoder and a single receiver (unicast), the VideoJet 8000 can enable multiple receivers to receive the video signal from an encoder simultaneously. This is achieved either by duplicating the data stream in the unit with subsequent distribution to multiple receivers (multi- unicast) or by distribution of a single data stream over the network to a number of receivers in a defined group (multicast).
  • Page 105 When the multicast address is set to 0.0.0.0, the VideoJet 8000 operates in multi- unicast mode (copies the data streams on the unit). If a valid multicast group IP address is entered for each encoder, the unit operates in the multicast mode (duplication of the data stream on the network).
  • Page 106 Keep a record of these numbers in case technical assistance is required. Hardware version: The hardware version number of the VideoJet 8000 is displayed. Software version: The software version number of the VideoJet 8000 is displayed. Livepage configuration In this dialog, the appearance of the Livepage can be set up to suit your requirements.
  • Page 107 Either GIF or JPEG images can be used. The file paths must correspond to the access mode (local paths such as C:\Images\Logo.gif for local files and URLs such as http://www.vcs.com/images/logo.gif for files on the Internet). Please note for access via Internet/intranet that there must be a connection in order to display the image.
  • Page 108 – If necessary, click Search to find a suitable folder. Path for JPEG and MPEG files: Enter the full path for saving snapshots and video sequences to be saved from the Livepage or HDD playback. – If necessary, click Search to find a suitable folder. VideoJet 8000...
  • Page 109 Software update Software update: The VideoJet 8000 is designed in such a way that its functions and parameters can be updated with firmware. To accomplish this, the current firmware is loaded on the unit via the selected network. It will be installed automatically after the connection is closed.
  • Page 110 (e.g. 192.168.0.80/main.htm) and hit return. – Repeat the upload. Configuration download: The VideoJet 8000 configuration data can be saved on a computer and the saved data loaded on a unit from the computer. – Click Download. A dialog will appear.

  • Page 111: Function Test

    The VideoJet 8000 offers a number of configuration options. Therefore you should check that it works properly after installation and configuration. This is the only way to ensure that the VideoJet 8000 will function as intended in an alarm situation.
  • Page 112 Configuration using a Web Browser Chapter 5 VideoJet 8000...

  • Page 113: Chapter 6 Operation

    Operation with Microsoft Internet Explorer A computer with Microsoft Internet Explorer (version 5.5 or later) can be used to receive live images from the VideoJet 8000, control cameras or other peripherals and replay sequences stored on the local hard drive.
  • Page 114 The following default address has been pre-set at the factory: 192.168.0.1 – Start the Web browser. – Enter the IP address of the VideoJet 8000 as the URL. The connection will be established, and after a short time the Livepage with the video image will appear.
  • Page 115 Chapter 6 Operation VideoJet 8000 password protection If the VideoJet 8000 is password-protected against unauthorized access, a password dialog will appear first. Note Configuration work can only be performed on a password-protected VideoJet 8000 unit if the service user is logged on.
  • Page 116 These messages can be saved automatically in a log file (see page 108). System minutes The System minutes field contains information about the operating status of the VideoJet 8000 and the connection. These messages can be saved automatically in a log file (see page 108). VideoJet 8000...
  • Page 117 VideoJet 8000. If a controllable device is connected to the VideoJet 8000 and configured, the controls for the peripheral are displayed next to the video image. – To control a peripheral device click the associated operating elements.

  • Page 118: Saving Snapshots

    MPEG format. – Click the MPEG Recording icon. Saving begins immediately. The storage location depends on the configuration of the VideoJet 8000 (see page 108). A recording in progress is indicated by the blinking of the red dot on the icon.

  • Page 119: Recordings In Progress

    Chapter 6 Operation Recordings in progress During automatic recording to the hard drive of the VideoJet 8000 by one of the background programs, the hard drive icon under the video image on the Livepage changes. It is animated to indicate that a recording is in progress. If no recording is taking place the icon is static.

  • Page 120: Playback Of Recorded Sequences

    – Click a camera name to list the recordings for that camera. – Click a list entry. Playback of the selected sequence will begin immediately in the video window. VideoJet 8000...
  • Page 121 The buttons below the video image can be used to control playback. The buttons have the following functions: Jump to the beginning of the video sequence, jump to the previous alarm Fast rewind, rewind in intervals of 0.5 sec (only in Pause mode) Stop VideoJet 8000...

  • Page 122: Backup

    Backup You can back up video recordings from the VideoJet 8000 hard drive directly to the hard drive of your computer. First select the sequence to save as described above. The following buttons are...

  • Page 123: Mpeg Viewer Installation

    The location for saving sequences and snapshots can be specified in the VideoJet 8000 settings (see page 108). MPEG viewer installation Saved sequences can also be displayed using the MPEG viewer from VCS. You will find the VCS MPEG viewer on the accompanying software CD. Note...

  • Page 124: Hardware Connections Between Vcs Units

    Chapter 6 Hardware connections between VCS units A VideoJet 8000 with a camera connected to it can be used as a transmitter and an MPEG-2 hardware decoder from VCS (such as the VIP 1000) with a connected monitor as a receiver using an Ethernet network connection. This way it is possible to cover large distances without installation or cabling challenges.
  • Page 125 – Select a transmitter from the Available sender units list. A JPEG snapshot of the video source selected will be displayed on the page. – Click Connect to begin showing the video images on the connected monitor. VideoJet 8000...

  • Page 126: Closing The Connection

    – Click Disconnect to stop the video display on the monitor. Operation with decoder software The VideoJet 8000 video server and VIDOS software from VCS together comprise a high-performance system solution. VIDOS is software for operating, controlling and administering CCTV installations (such as surveillance systems) at remote locations.

  • Page 127: Front Panel Controls

    Chapter 6 Operation Front panel controls The front panel of the VideoJet 8000 has various operating and display elements (see page 15). You can view some of the key configuration parameters on the display. However, the parameters cannot be changed here.
  • Page 128 Motion Alarm Shows the camera inputs currently receiving a motion signal (designation H). EthTX EthRX Current data transmission rate from and to the VideoJet 8000. HDD Throughput Current recording rate on the VideoJet 8000 hard drive. SW version Software version number for the VideoJet 8000.
  • Page 129 Chapter 6 Operation Date Time Information on the date and time settings. System uptime Operating time of the unit since it was last switched on or reset (in days, hours, minutes and seconds). VideoJet 8000...
  • Page 130 Operation Chapter 6 VideoJet 8000...

  • Page 131: Chapter 7 Maintenance And Upgrades

    IP address, subnet address and gateway address. Repairs Warning! Never open the casing of the VideoJet 8000 yourself, there are no user serviceable parts inside. Ensure that maintenance or repair work is performed only by qualified personnel (electrical technicians), or contact your VCS service center.

  • Page 132: Transfer And Disposal

    Maintenance and Upgrades Chapter 7 Transfer and disposal The VideoJet 8000 should only be passed on together with this manual. The unit contains environmentally hazardous materials that must be disposed of according to law. Defective or superfluous units and parts should be disposed of professionally or taken to your local collection point for hazardous materials.

  • Page 133: Chapter 8 Appendix

    Appendix Troubleshooting If you cannot correct a malfunction, please contact your supplier, system integrator or VCS customer service (Support@vcs.com). The version numbers of the internal processors can be viewed on a special page. Please note this information before contacting Customer Service.
  • Page 134 The unit is no longer Power failure during Have the unit checked by Customer ready for operation programming by the update Service and replaced if necessary. after a firmware file. upload. VideoJet 8000...

  • Page 135: Leds

    Chapter 8 Appendix LEDs The VideoJet 8000 network video server is equipped with several LEDs that show the operating status and can give indications of possible malfunctions: Power Not lit: Device is switched off. Lit green: The unit is switched on, no connection.

  • Page 136: Rs232/Rs422/Rs485 Interface

    RxD (receive data) RxD+ (receive data plus) CTS (clear to send) RxD- (receive data minus) – – – – GND (ground) GND (ground) – – TxD (transmit data) TxD- (transmit data minus) RTS (ready to send) TxD+ (transmit data plus) VideoJet 8000...

  • Page 137: Glossary

    Internet. It is usually written in dotted decimal notation with periods separating the bytes, for example "209.130.2.193". ISDN Integrated Services Digital Network JPEG An encoding process for still images (Joint Photographic Experts Group) kBit/s Kilobits per second, the actual data rate See Local area network VideoJet 8000...
  • Page 138 Login protocol with which users can log on to a remote computer (host) on the Internet User Datagram Protocol Uniform Resource Locator Unshielded Twisted Pair See wide area network wide area network A long distance link used to extend or connect remotely located local area networks VideoJet 8000...

  • Page 139: Specifications

    EN 55103-1, -2; EN 55130-4; EN 55022; EN 55024; EN 61000-3-2; EN 61000-3-3; FCC 47 CFR Section 1 Part 15 Dimensions (w × h × l) 409.2 × 48.6 × 351.5 mm (including base and BNC connections) Weight approx. 6.0 kg (with 240 GB hard drive) VideoJet 8000...
  • Page 140 I, IP, IPB, IPBB Total delay (IP) 198/180 ms (PAL/NTSC) Refresh rate 1 to 50/60 fields/s adjustable (PAL/NTSC) Field/image-based coding Multiplex standard ISO/IEC 13818-1 (MPEG-2) Network protocols RTP, Telnet, UDP, TCP, IP, HTTP, IGMP, ICMP, ARP, DHCP, SNMP VideoJet 8000...
  • Page 141 117 Conventions 5 create partition 84 background image 69 backup 122 banners 68 danger 7 basic data 61 data bits 41 baud rate 40 data interface 21 browser window 115 data terminal 23 data transfer 15 VideoJet 8000...
  • Page 142 28 interface mode 41 Ethernet 64 interface parameters 40 event log 116 internal clock 63 expert mode 30 IP address 24 false alarms 38 language 62 frame rate 53 language selection 74 front panel 15 LED 15 VideoJet 8000...
  • Page 143 56 multicast connection 65 Profile 43 multicast function 11 profile configuration 80 multicast port 67 profiles 79 multi-unicast 65 protocol 21 protocols 140 name 62 network 20 Rear panel 14 network check 131 receiver 11 VideoJet 8000...
  • Page 144 21 serial port function 40 transmission rate 40 Signal source 20 transparent 40 snapshots 12 TTL 67 SNMP 97 Specifications 139 unicast 65 standards 140 unit date 74 startup 9 unit ID 62 stop bits 41 VideoJet 8000...
  • Page 145 74 upload file 109 URL 28 user 23 user name 29 ventilation 18 version 106 video inputs 14 video loss alarm 36 video sensor 37 video sequence recording 118 video sources 20 voltage level 42 watermarking 77 VideoJet 8000...
  • Page 146 Index Chapter 9 VideoJet 8000...
  • Page 147 VideoJet 8000...
  • Page 148 VCS Video Communication Systems AG Forchheimer Strasse 4 90425 Nuremberg, Germany Phone: +49 911 93456-0 Fax: +49 911 93456-66 E-mail: info@vcs.com http://www.vcs.com ID No.: 2906/0804/e/1...

Table of Contents
