1.2 Features

• PCI Specification 2.1/2.2 compliant
• Speeds up to 921.6 kbps
• 16PCI952/954 , 16C954 UARTs with 128-byte FIFOs standard
• I/O address automatically assigned by PCI plug-and play
• OS supported: Windows 98/ME/2000/XP, Linux
• Optional surge protection
• Optional isolation protection for RS-232/422/485
• Interrupt status register for increased performance
• Space reserved for termination resistors
• Automatic RS-485 data flow control
• Utility-ICOM Tools

1.3 Specifications

• Bus Interface:
PCI bus specification 2.1 compliant for: PCI-1601A/B, PCI-1602A/B,
PCI-1610A/B, PCI-1612A/B, and PCI-1620A/B.
PCI bus specification 2.2 compliant for: PCI-1601AU/BU,PCI-
1602AU/BU, PCI-1602UP, PCI-1603, PCI-1604UP, PCI-1610CU/
AJU/AUP/UP, PCI-1611U, PCI-1612AU/U/CU, PCI-1620AU/U and
PCI-1622CU
• IRQ: all ports use the same IRQ assigned by PCI Plug-and-Play
• Data bits: 5, 6, 7, 8
• Stop bits: 1, 1.5, 2
• Parity: none, even, odd
• Communication Controller:
16PCI954 + 16C954 for PCI-1620A/B/AU/Uand PCI-1622CU
16PCI954 for PCI-1610A/AJU/B/CU/AUP/UP, PCI-1611U and PCI-
1612A/B/AU/U/CU
16PCI952 for PCI-1601A/AU/B/BU, PCI-1602A/AU/B/BU/UP,
PCI-1603 and PCI-1604UP
3 Chapter 1
