• Speed (bps) :
PCI-1603: RS-232: 50~203.4k
Current Loop: 50~57.6k
Others: 50 ~ 921.6 k
• Data Signals:
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND (for RS-232)
RI (for PCI-1603, PCI-1604UP, PCI-1610A/AJU/B/CU/AUP/UP)
TxD, RxD, RTS, CTS (for RS-422/485)
Tx+, Tx-, Rx+, Rx- (for PCI-1603 Current loop)
Data+, Data-, GND (for PCI-1602UP RS-485)
TxD, RxD, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-, GND (for PCI-
1602UP RS-422)
• Dimensions:
185 x 100 mm (for PCI-1610CU, PCI-1611U, PCI-1612A/B/AU/U/
CU, PCI-1620A/B/AU/U, PCI-1622CU)
123 x 92 mm (for PCI-1601A/AU/B/BU, PCI-1602A/AU/B/BU, PCI-
1603, and PCI-1610A/AJU/B)
119.91x 64.41mm (Low Profile PCI MD1 for PCI-1602UP,
PCI-1604UP and PCI-1610AUP/UP)
• Power Consumption
Model
PCI-1601A/AU/B/BU
PCI-1602A/AU/B/BU
PCI-1602UP
PCI-1603
PCI-1604UP
PCI-1610A/B
PCI-1610CU
PCI-1610AJU/AUP/UP
PCI-1611U
PCI-1612A/B/AU/U
PCI-1612CU
PCI-1620A/B/AU/U
PCI-1622CU
PCI-COMMUNICATION User Manual
Typical
220 mA (+5V)
250 mA (+5V)
-
250 mA (+5V)
-
60 mA (+12 V)
150 mA (+5 V)
-
-
-
270 mA (+5 V)
758 mA (+5V)
120 mA (+12 V)
180 mA (+5 V)
-
4
Max
270 mA (+5V)
300 mA (+5V)
300 mA (+5V)
300 mA (+5V)
300 mA (+5V)
80 mA (+12 V)
180 mA (+5 V)
750mA(+5V)
400 mA (+5V)
600mA(+5V)
338 mA (+5 V)
803 mA (+5V)
150 mA (+12 V)
220 mA (+5 V)
600mA(+5V)
