Copyright
This documentation and the software included with this product are copy-
righted 2001 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties which may result
from its use.
Acknowledgments
PC-LabCard is a trademark of Advantech Co., Ltd. IBM and PC are
trademarks of International Business Machines Corporation. MS-DOS,
Windows, Microsoft Visual C++ and Visual BASIC are trademarks of
Microsoft Corporation. Intel and Pentium are trademarks of Intel Corpo-
ration. Delphi and C++ Builder are trademarks of Inprise Corporation.
CE notification
The PCI-1761, developed by ADVANTECH CO., LTD., has passed the
CE test for environmental specifications when shielded cables are used
for external wiring. We recommend the use of shielded cables. This kind
of cable is available from Advantech. Please contact your local supplier
for ordering information.
On-line Technical Support
For technical support and service, please visit our support website at:
http://www.advantech.com/support
Note:
✎ Concerning saving the environment, we'd like to reduce the paper
used for the user's manuals. Starting with Appendix C, please
find the PDF file on the CD-ROM.
Part No. 2003176100
Printed in Taiwan
1st Edition
November 2001
Advertisement
Table of Contents
Related Manuals for Advantech PCI-1761
Summary of Contents for Advantech PCI-1761
- Page 1 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
-
Page 3: Table Of Contents
C.3 Relay I/O Registers - BASE+0H ......... 28 C.4 Isolated Digital Input Registers - BASE+1H ...... 29 C.5 Board ID - BASE+2H............29 C.6 Interrupt Status Register - BASE+3H/4H/5H ..... 30 C.7 Interrupt Control Register - BASE+3H/4H/5H ....31 Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com... - Page 4 Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com...
-
Page 5: Chapter 1 Introduction
..Chapter Chapter 1 Introduction Thank you for buying the Advantech PCI-1761. The Advantech PCI- 1761 is a 8-channel relay actuator and 8-channel isolated digital input card for the PCI bus. Its eight on-board SPDT relays are ideal for applications such as device ON/OFF control or small power switched. - Page 6 , the PCI-1761 can still manage to work properly albeit only for short period of time. Wide Input Range The PCI-1761 has a wide range of input voltage from 10 to 50 V , and it is suitable for most industrial applications with 12 V...
-
Page 7: Applications
❏ Testing & Measurement ❏ Laboratory & Education ❏ External relay driving 1.3 Installation Guide Before you install your PCI-1761 card, please make sure you have the following necessary components: ❏ PCI-1761 card ❏ PCI-1761 User's Manual ❏ Driver software... - Page 8 Install Hardware and Turn on PC Power Use driver utility to configure hardware Use test utility to test hardware Read examples and driver manual Start to write your own application Fig. 1-1: Installation Flow Chart PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com...
-
Page 9: Software Overview
DLL Driver The Advantech DLL Drivers software is included on the companion CD- ROM at no extra charge. It also comes with all the Advantech DA&C cards. Advantech's DLL driver features a complete I/O function library to help boost your application performance. The Advantech DLL driver for Windows 95/98/NT/2000 works seamlessly with development tools such as Visual C++, Visual Basic, Inprise C++ Builder and Inprise Delphi. -
Page 10: Dll Driver Programming Roadmap
❏ C++ Builder For instructions on how to begin programming works in each develop- ment tool, Advantech offers a Tutorial Chapter in the DLL Drivers Man- ual for your reference. Please refer to the corresponding sections in this chapter on the DLL Drivers Manual to begin your programming efforts. - Page 11 Programming with DLL Driver Function Library Advantech DLL driver offers a rich function library to be utilized in vari- ous application programs. This function library consists of numerous APIs that support many development tools, such as Visual C++, Visual Basic, Delphi and C++ Builder.
-
Page 12: Accessories
Chapter 1 Introduction 1.6 Accessories Advantech offers a complete set of accessory products to support the PCI-1761 card. These accessories include: Wiring Cable PCL-10137 The PCL-10137 shielded cable is specially designed for PCI-1761 cards to provide high resistance to noise. To achieve a better signal quality, the signal wires are twisted in such a way as to form a "twisted-... -
Page 13: Chapter 2 Installation
This chapter gives users a package item checklist, proper instructions about unpacking and step-by-step procedures for both driver and card installation. 2.1 Unpacking After receiving your PCI-1761 package, please inspect ita contents first. The package should contain the following items: PCI-1761 card Companion CD-ROM (DLL driver included) - Page 14 Note: ✎ Keep the anti-static bag for future use. You might need the original bag to store the card if you have to remove the card from PC or trans port it elsewhere. PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com...
-
Page 15: Switch And Jumper Settings
Some users will want the capability of clearing each relay output when the system (or PC) issues a reset signal on the PCI bus. Some users will want to clear their relays only as part of system power-on. The PCI-1761 satisfies both these needs by providing jumper JP2. Depending on the application, this capability may allow relay outputs to be "OFF"... -
Page 16: I/O Connectors
IDI 2A IDI 3B IDI 3A IDI 4B IDI 4A IDI 5B Note: IDI 5A IDI 6B Isolated Digital Input is bidiretional. IDI 6A IDI 7B IDI 7A Fig. 2-2: I/O connector pin assignments PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com... -
Page 17: Driver Installation
1761 card into your system, since this will guarantee a smooth instal lation process. The 32-bit DLL driver Setup program for the PCI-1761 card is included on the companion CD-ROM that is shipped with your DA&C card pack- age. Please follow the steps below to install the driver software: Step 1: Insert the companion CD-ROM into your CD-ROM drive. - Page 18 Fig. 2-4 Different options for Driver Setup For further information on driver-related issues, an online version of DLL Drivers Manual is available by accessing the following path: Start/Programs/Advantech Driver for 95 and 98 (or for NT/2000)/ Driver Manual PCI-1761 User’s Manual Advantech Co., Ltd.
-
Page 19: Hardware Installation
After the DLL driver installation is completed, you can now go on to install the PCI-1761 card in any PCI slot on your computer. But it is sug- gested that you should refer to the computer user manual or related docu- mentation if you have any doubt. - Page 20 1. Access the Device Manager through Control Panel/System/Device Manager. 2. The device name of the PCI-1761 should be listed on the Device Man- ager tab on the System Property Page. Fig. 2-5 The device name listed on the Device Manager Note: ✎...
-
Page 21: Device Setup & Configuration
The Device Installation program is a utility that allows you to set up, con- figure and test your device, and later stores your settings on the system registry. These settings will be used when you call the APIs of Advantech 32-bit DLL drivers. - Page 22 Select the device you want to configure from the list box and press the OK button. After you have clicked OK, you will see a Device Setting dialog box such as the one in Fig. 2-9. PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com...
- Page 23 Fig. 2-9 The Device Setting dialog box Step 5: After you have finished configuring the device, click OK and the device name will appear in the Installed Devices box as seen in Fig. 2.10 Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com...
- Page 24 Fig. 2-10 The Device Name appearing on the list of devices box Note: ✎ As we have noted, the device name "000:PCI-1761 I/O=6500H" begins with a device number "000", which is specifically assigned to each card. The device number is passed to the driver to specify which device you wish to control.
-
Page 25: Chapter 3 Signal Connections
PCI- 1761 via the I/O connector. 3.2 Isolated Digital Input Connections The PCI-1761 has 8 isolated digital input channels designated IDI0~IDI7. Each of isolated digital input channel accepts 10~50 V voltage inputs, and accept bi-directional input. -
Page 26: Relay Connections
Chapter 3 Signal Connections 3.3 Relay connections After power on, the initial relay output status of PCI-1761 is shown as below: Figure 3-2: Relay output connection A write operation to I/O address, BASE +0, will change the output status of each relay. For example, if Bit 0 of BASE +0 is set "1" (logic high), relay 0, K0, will switch from position "NORMALLY CLOSED",... -
Page 27: Appendix A Specifications
1 min. (Between coil and contacts) Operate time 15 ms max. Release time 5 ms max. Insulation Resistance 1,000 MΩ min. (at 500 V Mechanical 2x10 ops. min. Life Expectancy Electrical 2x10 ops. min.(contact rating) Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com... - Page 28 0 ~ +60 °C (32 ~ 140°F) (refer to IEC 68-2-1,2) Temperature Storage -20 ~ +70 °C (-4 ~158 °F) 5 - 95 % RH non-condensing Relative Humidity (refer to IEC 68-2-3) Certification CE Class A certified PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com...
-
Page 29: Appendix B Block Diagram
B B B B Appendix Appendix B Block diagram Fig B-1: System block diagram Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com... -
Page 30: Appendix C Register Structure And Format
For example, BASE+0 is the card's base address and BASE+7 is the base address plus seven bytes. Table C-1 shows the function of each register of the PCI-1761 or driver and its address relative to the card's base address. - Page 31 IDI0RF Interrupt Triggering Register IDI7RF IDI6RF IDI5RF IDI4RF IDI3RF IDI2RF IDI1RF IDI0RF Interrupt Flag IDI7F IDI6F IDI5F IDI4F IDI3F IDI2F IDI1F IDI0F Interrupt Clear Register IDI7CLR IDI6CLR IDI5CLR IDI4CLR IDI3CLR IDI2CLR IDI1CLR IDI0CLR Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com...
-
Page 32: Relay I/O Registers - Base+0H
Appendix C Register Structure and Format C.3 Relay I/O Registers - BASE+0H The PCI-1761 offers 8-ch relay actuators. These I/O channels use the input and output ports at addresses BASE+0H. Table C-2: Register for relay output status Read Relay Output Status... -
Page 33: Isolated Digital Input Registers - Base+1H
C.4 Isolated Digital Input Registers - BASE+1H The PCI-1761 offers 8-ch isolated digital input channels. These channels use the input ports at addresses BASE+1H. Table C-4: Register for isolated digital input Read Isolated Digital Input Bit # BASE +1H IDI7... -
Page 34: Interrupt Status Register - Base+3H/4H/5H
Interrupt triggering control bits (n = 0 ~ 7) The interrupt can be triggered by a rising edge or falling edge of the interrupt signal, as determined by the value in this bit. 0 Rising edge trigger 1 Falling edge trigger PCI-1761 User’s Manual Advantech Co., Ltd. www.advantech.com... -
Page 35: Interrupt Control Register - Base+3H/4H/5H
Interrupt triggering control bits (n = 0 ~ 7) The interrupt can be triggered by a rising edge or falling edge of the interrupt signal, as determined by the value in this bit. 0 Rising edge trigger 1 Falling edge trigger Advantech Co., Ltd. PCI-1761 User’s Manual www.advantech.com...
