3
Use the blower accessory to blow off any dirt from the surface of the starting sensor, skew sensor
(left), skew sensor (right) and ending sensor.
4
Use the blower accessory to blow off any dirt from the reflector sheets for the starting sensor, skew
sensor (left), skew sensor (right) and the ending sensor.
Reflector sheet for
starting sensor
Reflector sheet for
skew sensor (left)
5
Close the exit door.
• When you close the exit door, close it securely until the door is locked. Do not slam the exit
door.
Skew sensor (left)
Starting sensor
Reflector sheet for
skew sensor (right)
www.bbhscanners.com
Ending sensor
Skew sensor (right)
Reflector sheet for
ending sensor
