Cleaning the Drive Rollers, Free Rollers and Exit Rollers in the Exit Door

1
Press the power switch to the OFF position.
2
Pull the exit door release lever to open the exit door.
3
Use the roller cleaning paper to remove the dirt from the surfaces of the four (4) drive rollers and
the two (2) exit rollers.
Hold the roller to prevent it from rotating, then wipe the roller from one side to the other in the
direction of the arrows shown in the diagram. Turn the roller as you continue to wipe and clean all
the way around the roller.
Exit door release
www.bbhscanners.com
Exit rollers
Drive rollers
Drive rollers
