The scanner package includes 64 MB of base memory installed on the interface board. Some scanning
work may require additional memory depending on variables such as the size of the sheets to be scanned
and the image resolution settings. For example, two-sided scanning of larger sheet sizes such as A3 or
color scanning at a resolution of 600 DPI may require additional memory.
To add memory, please read the following information and follow the installation procedures.
The following DIMM (Dual Inline Memory Module) specifications are recommended for the Trūper scanner:
• JEDEC-Standard 168 pin, dual in-line memory module (DIMM)
• Nonbuffered
• Single +3.3V±0.3V power supply
• Frequency/CAS Latency: 100MHz/CL=2, 133MHz/CL=2, 133MHz/CL=3
• A single 64MB, 128MB, 256MB, or 512MB module may be added
The following DIMM brands and modules have been evaluated and approved for use with this scanner:
• EDGE 128MB Module
• EDGE 256MB Module
• EDGE 512MB Module
• Kingston 128MB Module
• Kingston 256MB Module
• Kingston 512MB Module

Removing the Interface Board

1
Press the power switch to the OFF position.
2
Disconnect the power cord from the electrical outlet and disconnect the computer interface cable.
Appendix 4—Adding Memory

Recommended DIMM Specifications

www.bbhscanners.com

Installing a DIMM Module
