Böwe Bell + Howell truper 3200 Operator's Manual page 84

3
Use the roller cleaning paper to remove the dirt from the surfaces of the four (4) drive rollers.
Hold the roller to prevent it from rotating, then wipe the roller from one side to the other in the
direction of the arrows shown in the diagram. Turn the roller as you continue to wipe and clean all
the way around the roller.
4
Use the roller cleaning paper to remove the dirt from the surfaces of the four (4) free rollers.
Hold the roller to prevent it from rotating, then wipe the roller from one side to the other in the
direction of the arrows shown in the diagram. Turn the roller as you continue to wipe and clean all
the way around the roller.
5
Close the ADF door.
• When you close the ADF door, close it securely until the door is locked. Do not slam the ADF
door.
6
Proceed to the following section, "Cleaning the Drive Rollers, Free Rollers and Exit Rollers in the
Exit Door".
Drive rollers
Free rollers
www.bbhscanners.com
Drive rollers
84 of 150
