Connecting the Scanner

1
Turn off the power for the computer.
2
Plug the scanner power cord into the AC power input on the back of the scanner and connect the
other end to a power outlet.
3
Connect the supplied USB cable to an available USB 2.0 port on the computer and connect the
other end to the USB connector on the scanner.
• Use the supplied USB cable.
• Do not connect the scanner to a USB hub. A hub connection is not guaranteed to work.
AC input
Note
Do not connect a USB and a SCSI cable to the scanner at the same time.
Power cord
USB cable
www.bbhscanners.com

Initial Setup and Installation

USB connector
