Chapter 1 – Product Overview
This User Guide describes the MultiModem® rCell intelligent wireless routers with an Ethernet II interface. You
can configure the MultiModem rCell Router for one of three connectivity modes: always-on, wake-up on ring, or
dial-on demand.
The always-on network connection automatically establishes a wireless data connection and allows for around the
clock surveillance, monitoring or real time data acquisition of any remote Ethernet device such as a Web camera.
If the data link is dropped due to poor reception or a complete loss of service, this feature automatically re-
establishes the data link.
The wake-up on ring configuration allows the router to "wake up" and initiate a connection when it detects an
incoming ring. For security reasons, you can setup the router to wake up based on a particular caller ID number.
This configuration is ideal for reducing the costs associated with the modem being online and available 24/7.
When configured for dial-on demand, the router only accesses the Internet when data is present. This
configuration is ideal for sharing Internet access among networked computers.
Model
MTCBA-E1-EN2
MTCBA-E1-EN2-GP
MTCBA-G2-EN2
MTCBA-G2-EN2-GP
MTCBA-C1-EN2
MTCBA-C1-EN2-GP
MTCBA-H5-EN2
MTCBA-H5-EN2-GP
MTCBA-EV2-EN2
MTCBA-EV2-EN2-GP
MultiModem rCell User Guide
Description
Quad-band E-GPRS Class 12 performance without GPS option
Quad-band E-GPRS Class 12 performance with GPS option
Quad-band GPRS Class 10 performance without GPS option
Quad-band GPRS Class 10 performance with GPS option
Multi-band CDMA2000 1xRTT performance without GPS option
Multi-band CDMA2000 1xRTT performance with GPS option
Tri-band UMTS/HSPA 7.2 performance without GPS option
Tri-band UMTS/HSPA 7.2 performance with GPS option
Dual-band 800/1900 MHz EV-DO Rev A performance without GPS option
Dual-band 800/1900 MHz EV-DO Rev A performance with GPS option
