Multitech MultiModem rCell User Manual page 23

Chapter 1 – Product Overview
Antenna Loss
TRP/TIS
GSM/EGSM RF Specifications
Frequency RX
Frequency TX
MultiModem rCell User Guide
Free space not to exceed -3dB
The total radiated power (TRP) at the antenna shall be no less than +21/20 dBm for PCS/CELL
channels respectively, and the total isotropic sensitivity (TIS) at the antenna shall be no less
than -104/104 dBm for PCS/CELL channels respectively.
GSM 850 EGSM 900
869 to 894 MHz 925 to 960 MHz
824 to 849 MHz 880 to 915 MHz
GSM 1800 GSM 1900
1805 to 1880 MHz 1930 to 1990 MHz
1710 to 1785 MHz 1850 to 1910 MHz
23
