Chapter 3 – Using the Web Management Software
On the PPP > Wakeup-on-Call
2.
Wakeup-on-Call Configuration
Select Enable for Wakeup-on-Call.
●
Set the Time Delay to 3 seconds. You can use the 10 second default.
●
Ensure all Init Strings are empty.
●
Submit Button
●
●
Caller ID Configuration
Enter the string RING to the Caller ID list.
●
Click the Add Button to save the string to the Caller ID list.
●
To ensure your changes go into effect, click Save and Restart. The device saves all the settings and reboots
3.
the computer.
Example 4 – Set Up the Ethernet Router to Activate on Matching Caller IDs Only:
On the PPP > PPP Configuration
1.
PPP General
Make sure that PPP is Enabled.
●
Make sure Dial-on-Demand is Enabled.
●
Set the Idle Time Out to the number of seconds you desire.
●
Authentication
Your wireless service provider may require you to have a separate PPP username and password. If so,
●
enter them here.
Note: If a username and password are required, your wireless provider likely gave you these items when
you activated your account.
Modem Configuration
Make sure your Dial Number is entered correctly:
●
For GSM models, the Dial Number is *99***1#
For CDMA models, the Dial Number is #777
MultiModem rCell User Guide
screen, set up the following parameters:
Click the Submit button to save these settings.
screen, set up the following parameters:
57
