General Configuration Group

In the General Configuration group , set the general system-based parameters.
Date The system date: MM/DD/YYYY
Time HH:MM:SS. A real time clock is part of SNTP to display proper time.

IP Configuration Group

Use the IP Configuration group to configure the Ethernet interface. If desired see Appendix A for a table of commonly
supported subnets.
(Default is 192.168.2.1),
IP Address
Mask (Default 255.255.255.0),
(Default 0.0.0.0),
Default Gateway
Primary DNS (Default 0.0.0.0),
(Default 0.0.0.0).
Secondary DNS

Auto Dial out Configuration Group

Auto Dialout Check the box to enable or disable Auto Dialout. Default is Enable. The Auto Dialout settings allow you
to use the integrated cellular modem directly with no router functions. This is accomplished using
redirector software on your computer. This software creates a virtual serial port allowing your
computer to communicate with the integrated cellular modem over IP using telnet.
Raw Dialout Check the box to enable or disable raw mode for an Auto Dialout session. Default is Disable.
Check the box to enable or disable Auto Dialout Login feature. Default is Enable. The Auto Dialout port
Auto Dialout
is the telnet port used by the redirector software on your computer to communicate to the integrated
Login
cellular modem.
Auto Dialout Port Enter the serial Auto Dialout Port number. Default is 5000.
Check the box to enable or disable the EIA standard signal characteristics (time and duration) used
Handle EIA Signal
between different electronic devices.
Inactivity Enter the seconds that the auto dialout session stays active before going inactive.

Syslog Configuration Group

Check the box to enable or disable Syslog. Default is Disable.
Syslog
Syslog Server IP If a Remote Syslog Server IP Address is specified, the syslog feature acts as a remote Syslog.
Address

Auto Discovery Group

Auto Discovery
Server Port
Broadcast Timer
38
Check the box to enable or disable Auto Discovery to broadcast (MAC level), the MAC Address, IP
Address, and DHCP information to the configured server port. Default is Enable. The router sends a
broadcast packet on the specified server port every 10 seconds or whatever interval the broadcast
timer is set to.
Enter the Server Port Number. Default port is 1020.
Enter the amount of time in seconds for the auto-discovery packet granularity of periodic
broadcasting. Default is 10 seconds.
