Caller ID Configuration Group

Add "Wakeup on Call" Caller ID:
wake up the router. Enter 'RING' (all Caps) to wake up on any call. Enter a CID phone number or an SMS message.
Ensure the SMS message string does not contain any spaces between words.
After entering the Caller ID, click the Add button. The Caller ID displays at the bottom of the page. You can enter
any number of IDs.
A Caller ID can be edited or deleted using Options, which are available once a Caller ID is displayed.
Caller Acknowledgement Configuration
Acknowledgement String to Caller:
cellular modem upon receiving a valid caller ID from the WAN. The default is NULL string.
Note: If the string is not configured, acknowledgement to the caller is not sent upon successful caller ID reception.

Submitting and Saving Your Changes

To save these settings, click Submit.
To ensure your changes go into effect, click Save and Restart.

Wakeup-On-Call Examples

Example 1 – Set Up the Ethernet Router to Activate on Incoming SMS Message
On the PPP > PPP Configuration
1.
PPP General
●
Make sure that PPP is Enabled (the default).
Make sure Dial-on-Demand is Enabled (the default).
Set the Idle Time Out to the number of seconds you desire.
Authentication
●
Your wireless service provider may require you to have a separate PPP Username and Password. If so,
enter them here.
Note: If a username and password are required, your wireless provider likely gave these items to you
when you activated your account.
Modem Configuration
●
Make sure your Dial Number is entered correctly.
For GSM models, the Dial Number is *99***1#
For CDMA models, the Dial Number is
Enter your APN. Your wireless service provider assigns the APN.
Example: AT+CGDCONT=1,"IP","Internet" The Example: AT+CGDCONT=1,"IP","Internet" needs to be
removed. Just the APN name needs to be entered in the APN field.
To save the changes made on this page, click Submit.
2.
54
To add Caller ID to the Wakeup-on-Call function, enter the Caller ID that can
The configured string of (0 to 40 characters) that is sent to the integrated
page, configure the following parameters:
#777
