GSM Antenna Requirements/Specifications
Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization
Antenna Loss
TRP/TIS
GPS (Global Positioning) RF Specifications
Frequency RX
LNA Bias Voltage
LNA Current Consumption
GPS Antenna Requirements/Specifications
Frequency
Impedance
VSWR
Input voltage
GPS TIS

Global Positioning System (GPS)

Point the GPS toward the sky, as the GPS antenna needs to find the satellites that provide location information.
Global Positioning System (GPS) – Underwriters Laboratories, Inc. Statement
Underwriters Laboratories Inc. ("UL") has not tested the performance or reliability of the Global Positioning
System ("GPS") hardware, operating software or other aspects of this product. UL has only tested for fire, shock or
casualties as outlined in UL's Standard(s) for Safety.UL60950-1 Certification does not cover the performance or
reliability of the GPS hardware and GPS operating software. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS RELATED
FUNCTIONS OF THIS PRODUCT.
24
824 – 960 MHz / 1710 – 1990 MHz
50 Ohms
VSWR shall not exceed 2.0:1 at any point across the bands of operation
3 dBi on azimuth plane
Omni-directional
Vertical
Free space not to exceed -3db
Including cable loss the total radiated power (TRP) at the antenna shall be no less
than +22/24.5 dBm for 850/1900 MHz respectively, and the total isotropic
sensitivity (TIS) at the antenna shall be no less than -99/101.5 dBm for 850/1900
MHz respectively.
GPS L1
1575.42
5V
40mA Max
1575MHz
50 Ohms
1.5db
3.0V +/- 0.3V
The total isotropic sensitivity (TIS) at the antenna shall be no less than
47 dBm
