GPS
Accuracy
Open Sky TTFF
Sensitivity Tracking
Protocol

MTCBA-C1-EN2

General
Standards
Frequency Bands
Speed
Packet Data*
Circuit Switched Data
Physical Description
Dimensions
Weight
Connectors
Antenna Connector
LAN Connector
RS232 Connector
Power Connector
Environment
Operating Temperature** -40° to 185° F
Storage Temperature
Humidity
Power Requirements
Operating Voltage
Certifications and Compliance
EMC Compliance
Radio Compliance
Safety Compliance
GPS
Accuracy
Open Sky TTFF
Sensitivity Tracking
Protocol
14
Position 2.5m CEP, Velocity 0.1 m/sec
Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
-165 dBm
NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
CDMA2000 1xRTT
Dual band 800/1900 MHz
Up to 153.6 Kbps forward and reverse
IS-95A, IS-95B up to 14.4 Kbps forward and reverse
2.93 in x 7.0 in x 1.24 in
7.44 cm x 17.78 cm x 3.15 cm
0.75 lbs
0.340 Kg
50 ohm SMA (female connector)
RJ-45, 10/100 BaseT
DE9
2.5 mm miniature (screw-on)
-40° to 85° C
-40° to 185° F
-40° to 85° C
Relative humidity 20% to 90% noncondensing
9V to 32V DC
FCC Part 15
FCC Part 22, 24
UL/cUL 60950-1 2nd Ed
IEC60950-1 2nd Ed am.1
Position 2.5m CEP, Velocity 0.1 m/sec
Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
-165 dBm
NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
Chapter 1 – Product Overview
MultiModem rCell User Guide
