  • Page 1 ® MultiModem rCell Intelligent Wireless Router Quick Start Guide...
  • Page 2 Record of Revisions Revision Date Description 08/19/10 Initial release of MultiModem rCell with GPS and without GPS for C1,E1,G2,H4, and EV2 models. 10/25/10 Restructure installation and add carrier activation. Trademarks Trademarks and registered trademarks of Multi-Tech Systems, Inc. include MultiModem, the Multi-Tech logo, and Multi-Tech.

  • Page 3: Handling Precautions

    Introduction The purpose of this guide is to cover safety concepts, the basic connections, and general setup of the MultiModem rCell Intelligent Wireless Router. For detailed information refer to the User Guide which is available on your MultiModem CD accompanying your router product and on the Multi-Tech Web site.

  • Page 4: Ship Kit Contents

    MultiModem rCell Intelligent Wireless Router personnel have performed the installation. Verification of the protection of vehicle electronics should be part of the installation. ● The use of an alert device to operate a vehicle’s lights or horn on public roads is not permitted.

  • Page 5: Connect The Antenna And Power

    MultiModem rCell Intelligent Wireless Router Insert SIM Card, If required The MultiModem requires the power supply connection to begin operation. It also requires a SIM card (Subscriber Identity Module) to operate on a GSM network. To install the SIM, do the following: Using a small Phillips screwdriver, remove the two SIM door screws and remove the SIM door.
  • Page 6 MultiModem rCell Intelligent Wireless Router Using an Ethernet cable, connect one end of the cable to the ETHERNET connector on the back of the router and the other end to your PC either directly or via a switch or hub.
  • Page 7 MultiModem rCell Intelligent Wireless Router Notes The POWER LED. The POWER LED lights after power-up. Reset Button. Hold the Reset button in until the Status Light goes out. Then release it. It also will set the username and password back to admin and admin as well as setting the IP address to the default of 192.168.2.1.
  • Page 8 MultiModem rCell Intelligent Wireless Router ● Enter the PC IP Address. Example: 192.168.2.x. Note: The x in the address stands for numbers 101 and up. ● Enter the PC Subnet Mask. Example: 255.255.255.0 ● Enter the PC Default Gateway. Example: 192.168.2.1...
  • Page 9 MultiModem rCell Intelligent Wireless Router Setup Wizard Screen IP Configuration IP Address – The default is 192.168.2.1. To change it, simply enter your own IP address. Mask – The default is 255.255.255.0 DNS – Enter the primary DNS IP address for the system. The default is 0.0.0.0...

  • Page 10: Carrier Activation

    MultiModem rCell Intelligent Wireless Router Init String – 4 modem initialization strings are allowed. PPP Authentication Authentication Type – Click the button corresponding to the authentication protocol you want to use to negotiate with the remote peer. PAP, CHAP, or PAP-CHAP.

  • Page 11: Verifying Signal Strength

    MultiModem rCell Intelligent Wireless Router Note: If you need remote access to your MultiModem over the internet for remote configuration, you need to ensure that your wireless network provider has provisioned mobile terminated data and fixed or dynamic public IP address in which they can configure the network to redirect any incoming connection to that predefined IP.
  • Page 12 MultiModem rCell Intelligent Wireless Router Network Registration Verification Value Network Registration Status +CREG: 0,0 The router is not registered on any network +CREG: 0,1 The router is registered on the home network +CREG: 0,5 The router is registered on a network and it is...
  • Page 13 For detail procedures on carrier activation, please refer to the appropriate carrier activation notice supplied with your router, and the detailed carrier activation process in your MultiModem rCell User Guide contained on your MultiModem CD. Multi-Tech Systems, Inc. Quick Start Guide...
