GPS
Accuracy
Open Sky TTFF
Sensitivity Tracking
Protocol
*
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C
and has not been evaluated by UL for ambient greater than 40° C.
**
UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor
locations has not been evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor
applications or in ambient above 40° C.

MTCBA-H5-EN2

General
Standards
Frequency Bands
Speed
Packet Data*
Physical Description
Dimensions
Weight
Connectors
Antenna Connector
SIM Holder
LAN Connector
RS232 Connector
Power Connector
Environment
Operating Temperature** -22°to 167° F
Storage Temperature
Humidity
Power Requirements
Operating Voltage
SMS
SMS
16
Position 2.5m CEP, Velocity 0.1 m/sec
Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
-165 dBm
NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
HSPA+
Penta band 850/900/1700/1900/2100 MHz
HSDPA data service of up to 21.0 Mbps
HSUPA data service of up to 5.76 Mbps
2.93 in x 7.0 in x 1.24 in
7.44 cm x 17.78 cm x 3.15 cm
0.75 lbs
0.340 Kg
50 ohm SMA (female connector)
Standard 1.8 and 3V SIM receptacle
RJ-45, 10/100 BaseT
DE9
2.5 mm miniature (screw-on)
-30° to 75° C
-40° to 185° F
-40° to 85° C
Relative humidity 20% to 90% noncondensing
9V to 32V DC
Text and PDU
Point-to-Point
Cell broadcast
Chapter 1 – Product Overview
MultiModem rCell User Guide
