Tandberg Data
magazine release tool which is part of the accessory kit shipped together with the
StorageLoader. This tool must be entered through the hole marked in figure 4.21.
Note: The manual eject must only be used when power is turned off.
Enter the release tool in
hole four from the center

Figure 4.21 Pointing out hole used to insert release tool

Figure 4.22 shows the
release tool inserted into
the correct hole on the right
hand side magazine bezel.

4.9 Standby Functionality

On the front panel a standby button is available.
To activate Standby mode, press the button for a minimum of 2 second, the
StorageLoader will then enter a standby mode in a controlled manner. The following
takes place before the StorageLoader goes into standby mode.
1. Finish possible StorageLoader activity.
2. Controlled aborting of tape drive activity; buffered data is flushed to tape;
cartridge is unloaded from drive but not ejected.
3. The display is turned off.
4. No StorageLoader activity is allowed until standby button is pressed again.
5. While in standby mode, the attached server/host can see the two SCSI
40

Figure 4.22 Magazine release tool in use

StorageLoader Installation and User Manual
Operation and Configuration
