Tandberg Data Operation and Configuration
Dialogs and the Messages.

4.2.1 Menus

The major contributor is the MENU. It is used to select operations to perform by
enabling the operator to navigate a menu tree using the control buttons.
Due to the size of the display, only one menu item is shown at a time. See figure 4.4
for a standard menu layout and figure 4.5 for a complete menu tree.
▲ EXIT
Menu Entry.
▼ SELECT

Figure 4.4 Standard Menu Layout

The two filled arrows on the left are used to show the next (down arrow) and
previous (up arrow) entries on the current menu level.
The Exit button on the right is used to ascend to the menu level above, while the
Select button is used to descend to the submenu designated by the Menu Text, or to
activate the function selected if the Menu Entry describes a function.
24
