4.3 Main Menu

The Main menu contains a set of frequently used functions and links to a set of sub
menus.
Item name Description
Load to Drive Loads a cartridge from a selected magazine slot into the drive.
When Select is pressed on this menu item, a magazine slot
selection dialog is displayed. The operator has to scroll to the
wanted slot and press Ok to start the operation. The progress of
the operation is displayed, and when the loader part of the
operation is completed, the main menu is displayed.
The loader must be idle to make this function selectable.
See chapter:
Unload from Unloads a cartridge from the drive and stores it in a selected
Drive magazine slot. When Select is pressed on this menu item, a
magazine slot selection dialog is displayed. The operator has to
scroll to the wanted destination slot and press Ok to start the
operation. The progress of the operation is displayed, and when
the operation is completed, the main menu is displayed.
The loader must be idle to make this function selectable.
See chapter: To unload a cartridge from drive: for more details.
Eject Magazine Ejects one or both of the two magazines. When Select is pressed
on this item, a magazine selection menu is displayed. The operator
has to choose left, right or both magazines and press Ok to start
the operation. The progress of the operation is displayed, and
when the operation is completed, a status informing the operator
that one or both magazines are not in place is displayed.
The loader must be idle to make this function selectable.
See chapter Magazine Handling for more details.
Setup Selects the loader and drive setup functions. The loader must be
idle to make this function selectable.
See chapter Setup Menu for more details.
View Data Selects the access to loader and drive system data. This is the only
menu entry which is selectable when the loader is not idle.
See chapter View Data Menu for more details.
Utilities Selects a set of the loader and drive maintenance and diagnostic
functions. The loader must be idle to make this entry selectable.
See chapter Utilities Menu for more details.
The Main menu can be selected even if the loader is not in the idle state. While in
the main menu, the loader will accept and execute SCSI commands. When any of
the main menu entries except the View Data entry is selected, the loader will go to
it's busy state and SCSI commands will be terminated with Check Condition and
Not Ready status.
StorageLoader Installation and User Manual
To load a cartridge to the drive:
Operation and Configuration
for more details
