bracket. The power switch, the fuse holder (with a 250V 2A (H) fuse) and the AC
power cord connection are combined in one common unit.
SCSI Interface Connectors
The StorageLoader has two shielded 68-pin VHDCI SCSI connectors on the rear
panel. The connectors are used for connecting the tape drive and the StorageLoader
to a SCSI bus. These connectors can link to the following:
• A shielded male VHDCI SCSI cable
• A shielded male VHDCI SCSI terminator.
Ethernet Port
This port is for the Remote Management system and allows you to connect the
StorageLoader to a 10/100 BaseT Ethernet network.
Back Panel Cover Plate
Removing the Back Panel Cover Plate gives you access to all the field-replaceable
units located at the back of the StorageLoader.
