• View StorageLoader status and information
• Test StorageLoader functionality
Control Buttons
The labels for the four control buttons are displayed in the corners of the LCD. All
buttons have "soft labeling" for different modes of operation (i.e., the functions and
labels of the buttons change during different activities). The actual soft label for
each button for any activity is always visible on the display.
LED Indicators
The two LED indicators are green and amber. They indicate the StorageLoader
activity as follows:
• Green LED on: The StorageLoader is either running or ready for operation.
• Green LED blinking: Short blinks followed by long intervals indicate that
the loader is in low power standby mode.
• Amber LED on: Fault LED, the StorageLoader has encountered an electrical
or mechanical failure.
• Both LED's off: The StorageLoader is offline. This is the case while the
loader is initializing, after power-on, and when a magazine is removed.
Standby Switch
A switch on the front panel provides a Loader Standby. If the switch is pushed when
the loader is active, the loader will complete the current operation and go off line
and enter standby mode, see more details in chapter 4.9, Standby Functionality.
Magazine Front Bezel
The front bezel of the magazines is visible from the front. All magazine handling is
described in detail in chapter 4.8, Magazine Handling.

2.2.2 Internal Components

The StorageLoader features the main internal components shown in the figure
below.
