Page 1 BARCO PROJECTION SYSTEMS VISION 701 MULTIMEDIA R9000740 OWNER'S MANUAL Date: Rev. : Art. No. 070597 R5975238...
Page 2 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, May 1997. All rights reserved. Trademarks are the rights of their respective owners. Printed in Belgium...
Page 3: Table Of Contents
TABLE OF CONTENTS WARNINGS ......................1-1 SAFETY INSTRUCTIONS ................... 1-1 On safety ....................1-4 On installation ..................... 1-5 On servicing ....................1-6 On cleaning ....................1-6 On repacking ....................1-7 On illumination .................... 1-7 LOCATION AND FUNCTION OF CONTROLS ........... 2-1 Rear panel terminology ................
Page 4 TABLE OF CONTENTS GUIDED ADJUSTMENT MODE ................7-1 Start up of the guided adjustment mode............7-2 Overview flowchart 'Guided Adjustment' procedure........7-3 Selecting Setup Pattern ................7-4 Internal Cross Hatch Pattern ............... 7-5 Picture tuning ....................7-6 Sync Fast/Slow toggle ................. 7-6 Line Doubler (option) ...................
Page 5 TABLE OF CONTENTS Geometry Adjustments ................8-11 Horizontal Phase Adjustment ..............8-12 Raster Shift Adjustment ................8-14 Left-Right (east-west) Adjustments ............8-16 Top-Bottom (north-south) Adjustments ............8-18 Horizontal Size Adjustment ................ 8-20 Vertical Linearity Adjustment ..............8-21 Vertical Size Adjustment ................8-22 Blanking Adjustments ................
Page 6 TABLE OF CONTENTS Orbiting Kit ....................11-4 Soft edge matching kit ................11-4 Contrast modulation kit ................11-4 Appendix A : Battery replacement in the RCU............ A-1 Appendix B : Orbiting ..................B-1 Appendix C : Soft edge matching ................ C-1 Appendix D : Contrast modulation (option) ............
Page 7: Warnings
SAFETY INSTRUCTIONS WARNINGS SAFETY INSTRUCTIONS on safety on installation on servicing on cleaning on repacking on illumination R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 8 SAFETY INSTRUCTIONS Notice on Safety This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2 No.950, which are the safety standards of information technology equipment including electrical business equipment. These safety standards impose important requirements on the use of safety critical components, materials and isolation, in order to protect the user or operator against risk of electric shock and energy hazard, and having access to live parts.
Page 9 SAFETY INSTRUCTIONS The lightning flash with an arrowhead within a triangle is intended to tell the user that parts inside this product may cause a risk of electrical shock to persons. The exclamation point within a triangle is intended to tell the user that important operating and/or servicing instructions are in- cluded in the technical documentation for this equipment.
Page 10: On Safety
SAFETY INSTRUCTIONS * All the safety and operating instructions should be read before using this unit. * The safety and operating instructions manual should be retained for future reference. * All warnings on the equipment and in the documentation manuals should be adhered * All instructions for operating and use of this equipment must be followed precisely.
Page 11: On Installation
SAFETY INSTRUCTIONS B. Power cord with ANSI 73.11 plug: The wires of the power cord are colored in accor- dance with the following code. Green/yellow: ground White: neutral Black: line (live) 3. Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord.
Page 12: On Servicing
SAFETY INSTRUCTIONS This product should never be placed near or over a radiator or heat register. The projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided. On servicing Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials and risk of electric shock! Refer all servicing to qualified service personnel.
Page 13: On Repacking
SAFETY INSTRUCTIONS - To ensure the highest optical performance and resolution, the projection lenses are specially treated with an anti-reflective coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a damp cloth, detergent solution, or thinner.
Page 14 SAFETY INSTRUCTIONS R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 15: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS LOCATION AND FUNCTION OF CONTROLS Rear Panel Terminology Front Panel Terminology RCU Terminology R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 16: Rear Panel Terminology
LOCATION AND FUNCTION OF CONTROLS REAR PANEL TERMINOLOGY CO MM PO RT G ( S) RS 232 IN RS23 2O UT S- VI DE O R EM O T E V ID E O ( 800 per ipher als ) R - Y Y(S) RS232IN...
Page 17: Front Panel Terminology
LOCATION AND FUNCTION OF CONTROLS VIDEO IN (Composite video, 1x BNC connector): allows a video tape recorder, video camera, color receiver/monitor, etc. having video line output to be connected to the projector. S-VIDEO IN: Separated Y/C (luma-chroma) signal inputs and outputs for higher quality playback of Super VHS signals (4-pin S-VIDEO connector).
Page 18: Control Panel Terminology
LOCATION AND FUNCTION OF CONTROLS Control panel terminology a. The local keypad Getting access The local keypad is covered by a door on which the projector logo is screened. ADJ UST EXIT STANDBY ENTER To open this door, push as indicated on next drawing and turn it to the front side of the projector.
Page 19 LOCATION AND FUNCTION OF CONTROLS Local keypad A D J U S T E XI T S T A N D B Y E N T E R EXIT ENTER STBY PAUSE TEXT SHARPNESS TINT COLOR stand-by BRIGHTNESS pause/park CONTRAST sharpness tint color...
Page 20 LOCATION AND FUNCTION OF CONTROLS Back light key : when activated, all keys will be lit up and visible in the dark. ADJ. : adjust key, to enter or exit the adjustment mode. Address key (sunk key), to enter the address of the projector (between 0 and 9).
Page 21: Power (Mains) Connection
POWER CONNECTION POWER (MAINS) CONNECTION R59 75456 BARCOVISION 701 MULTIMEDIA 070497...
Page 22: Switching On/Off
POWER CONNECTION Power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. See installation instructions before connecting to t he supply V NO M 120/230 Volt I MAX 5/2.
Page 23: Source Connections
CONNECTIONS SOURCE CONNECTIONS - connecting a Video source - connecting a S-Video source - connecting a RGsB or RGBS analog source - connecting a RG3sB or RGB3S analog source - connecting a (R-Y)Ys(B-Y) or (R-Y)Y(B-Y)S analog source - connecting a (R-Y)Y3s(B-Y) or (R-Y)Y(B-Y)3S analog source PERIPHERAL EQUIPMENT CONNECTION - Connecting a computer, e.g.
Page 24: Signal Input Connection To The Projector
CONNECTIONS Signal input connection to the projector : - Composite Video (*) - S-Video (*) - RGBS or RGsB - RGB3S or RG3sB - (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) [component input] (**) - (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) [component input] (**) (*) If the line douoble feature is built in, this feature is available via a software on/off toggle. (**) If the line double feature is built in, this feature is available for component video signals on standard frequency via software on/off toggle.
Page 25: Connecting A Composite Video Source
CONNECTIONS Connecting a Composite Video source. Composite video signals from a VCR, OFF air signal decoder, etc.. If a line doubler is built in : the default position of this line doubler is ON (active), the video input signal will be displayed as a non interlaced image (= improved image stability). To enable or to disable this line doubler function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see Picture tuning in chapter 'Guided' adjustment mode or 'Random access' adjustment mode).
Page 26: Connecting A S-Video Source
CONNECTIONS - use the control disk to high- light 1. G EN ER AL A CC ES S - press ENTER to select the highlighted source. S H A R P N E S S T I N T C O L O R B R I G H T N E S S C O N T R A S T E n t er A D J U S T...
Page 27: Connecting A Rgb Analog Source With Composite Sync
CONNECTIONS S-Video input selection a. Press digit button 2 on the RCU or b. with the local keypad : (to gain access to the local keypad, see Local keypad in chapter Location and functions of control.) - Press ADJUST key, the General access menu is displayed on the screen. - Use the control disk to highlight 2.
Page 28 CONNECTIONS CO MM PO RT G ( S) S- VI DEO R E M O T E VI DE O RS23 2 IN RS232 O UT ( 800 per ipher als ) R - Y Y(S) AN AL O G O UT I NP U T RGBS or RGsB input selection a.
Page 29: Connecting A Rgb Analog Source With Tri-Level Sync
CONNECTIONS Connecting a RGB Analog source with Tri-level sync. RGB analog input terminals with Tri level sync input or with Tri-level sync on green. The projector detects automatically where the sync signal is located. CO MM PO RT G ( S ) S- VI DEO ( 800 peripher als ) RE MO TE VI DE O...
Page 30: Connecting A Component Source
CONNECTIONS Connecting a Component source. (R-Y)Y(B-Y) analog input terminals with sync input or with sync on the luminance (Y) input. The projector detects automatically where the sync signal is located. Line doubling is possible for component video input sources on standard line frequency.
Page 31: Connecting A Component Source With Tri-Level Sync
CONNECTIONS - Use the control disk to high- light 5. - Press ENTER to select the G E N E R A L A C C E S S highlighted source. S H A R P N E S S T I N T C O L O R B R I G H T N E S S...
Page 32 CONNECTIONS (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) input selection a. Press digit button 6 on the RCU or b. With the local keypad : (to gain access to the local keypad, see Local keypad in chapter Location and functions of control.) - Press ADJUST key, the General access menu is displayed on the screen. - Use the control disk to high- light 6.
Page 33: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs232 Input Of The Projector
CONNECTIONS Connecting a computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS232 input of the projector. The projector has a RS232 port that allows it to communicate with a computer. Applications: remote control and data communications. a) remote control: - easy adjustment of the projector via IBM PC (or compatible) or MAC connection.
Page 34: Connecting A Rcvds 05 Switcher To The Projector
CONNECTIONS PERIPHERAL EQUIPMENT Connecting a RCVDS 05 switcher to the projector. - Up to 10 inputs (20 inputs when video and S-video) with the RCVDS 05 switcher and up to 90 inputs when 10 RCVDS switchers are linked via the expansion modules. - Serial communication with the projector.
Page 35: Controlling
CONTROLLING CONTROLLING Battery installation in the RCU How to use the RCU Projector address How to display a projector address How to program an address into the RCU Input selection Picture controls The Pause key R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 36 CONTROLLING Battery installation in the RCU. A new battery (not yet installed to save the battery life time) is delivered inside the plastic bag with the power cord. Before using the RCU, start first the battery installation procedure. Remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU.
Page 37 CONTROLLING The BARCOVISION 701 MULTIMEDIA can be controlled with a. the RCU b. the hardwired RCU (cable not included) c. the local keypad. Controlling the projector with the RCU and the hardwired RCU is the same. How to use the RCU a) Point the front of the RCU towards the reflective screen surface Ce il in g I R s e n s o r...
Page 38 CONTROLLING R e a r s i d e o f p r o j e c t o r Front of projector 4 5 ° 4 5 ° 4 5 ° 4 5 ° E NT E R E NT E R FR EE Z F RE E Z R C U...
Page 39: Projector Address
CONTROLLING Projector address a. hardware set up of the projector address. Every projector requires an individual address between 0 and 16 which is set with hardware DIP switches inside the projector. To change that address, contact a BARCO authorized technician. b.
Page 40: How To Program An Address Into The Rcu
CONTROLLING How to program an address into the RCU? Press the ADDRESS key (recessed key on the RCU) with a pencil and enter the address with the digit buttons. That address can be any digit between 0 and 9. When programming '0', zero address, the RCU will control a projector regardless of the projector's address.
Page 41 CONTROLLING Use the control disk to highlight the desired source number. Push the G E N E R A L A C C E S S control disk up or down to move the cursor up and down, push the con- S H A R P N E S S T I N T trol disk to the left or to the right to...
Page 42: Picture Controls
CONTROLLING When a valid source number is selected, the projector will display this source or it will wait on the selected source number until the source becomes available. A mes- sage 'source not available' will be displayed for a short time. W A RN I N G sour ce not available...
Page 43 CONTROLLING G E N E R A L A C C E S S S H A R P N E S S T I N T C O L O R B R I G H T N E S S C O N T R A S T E n t er A D J U S T Select w ith...
Page 44 CONTROLLING Contrast Control A correct 'contrast' setting is impor- tant for good image reproduction. Adjust the contrast to the level you prefer, according to room lighting conditions. A bar scale gives a visual indication on the screen of the current con- trast setting while pressing the + or - buttons (RCU) or pushing the con- trol disk to the left or to the right...
Page 45: The Pause Key
CONTROLLING Tint Control Tint is only active for Video and S- Video. Tint control is effective only when using the NTSC 4.43 or NTSC 3.58 system. A bar scale gives a visual indication on the screen of the current tint setting while pressing the + or - buttons (RCU) or pushing the control disk to the left or to the right (local...
Page 46 CONTROLLING 5-12 R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 47: Start Up Of The Adjustment Mode
START UP OF THE ADJUSTMENT MODE START UP OF THE ADJUSTMENT MODE R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 48: Entering The Adjustment Mode
START UP OF THE ADJUSTMENT MODE Entering the adjustment mode A DJ U S T ME N T M OD E S el ect a pat h f rom be l o w : G U I D E D R A N D O M A C C E S S I N S T A L LA T I O N S E R V I C E...
Page 49: Adjustment Mode
START UP OF THE ADJUSTMENT MODE Adjustment mode All picture geometry and convergence adjustments are made while in the 'Adjustment mode'. Two possible ways to enter the adjustment mode : a) Using the RCU. Press the ADJUST key. The projector displays the path selection menu. b) Using the local keypad.
Page 50 START UP OF THE ADJUSTMENT MODE Note : to adjust the Analog picture control while in the 'Adjustment mode', press the ADJUST key. The next General Access menu will be displayed. Push the control disk up or down to select the analog con- G E N E R A L A C C E S S trol to be adjusted and press the ENTER key to confirm.
Page 51 START UP OF THE ADJUSTMENT MODE While in Guided or Random Access adjustment Mode, the user may use an external source, an internally generated genlocked pattern or an internally generated multifrequency cross hatch pattern as a setup pattern. Warning during the start up of the installation mode.
Page 52 START UP OF THE ADJUSTMENT MODE b) adjusting the projector with the local keypad. When the 'compose password' menu is displayed, select with con- C O M P O S E trol disk the first digit of your pass- P A S S W O R D word and press ENTER.
Page 53: Guided Adjustment Mode
GUIDED ADJUSTMENT MODE GUIDED ADJUSTMENT MODE R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 54: Start Up Of The Guided Adjustment Mode
GUIDED ADJUSTMENT MODE Start up of the guided adjustment mode. Push the control disk up or down to highlight GUIDED on the 'Adjustment mode' menu A DJ U S TM E NT M OD E and then press ENTER. S el ect a pat h f rom be l o w : G U I D E D The Guided Adjustment mode...
Page 55: Overview Flowchart 'Guided Adjustment' Procedure
GUIDED ADJUSTMENT MODE Overview flowchart 'Guided Adjustment' procedure. G U I D E D A D J U S T M E N T M O D E I NS U RE T HA T T HE P RO J E CT O R HA S B E E N I NS T A L L E D C OR RE CT L Y , Picture tuning A N D T H A T T HE L E N S E S / CR T S...
Page 56: Selecting Setup Pattern
GUIDED ADJUSTMENT MODE Selecting Setup Pattern If an external source is con- nected to the projector, the Setup pattern menu will be dis- C h o o s e a s et up pat t ern played. Push the control disk f ro m bel ow : up or down to highlight the desired setup pattern and then...
Page 57: Internal Cross Hatch Pattern
GUIDED ADJUSTMENT MODE Internal Cross Hatch Pattern The Internal # pattern menu will be displayed if the internal cross hatch pattern has been INTE RNA L # P A TTE RN selected or if no source is con- k H z / H z nected to the projector.
Page 58: Picture Tuning
GUIDED ADJUSTMENT MODE Picture tuning Depending on the source type (video, S-Video, RGB(S) analog with composite or Tri-level sync, component input with composite or Tri-level sync) the picture tuning menu offers the possibility to toggle : For Video, S-Video or Component video sources : - The Synchronisation speed - The Line Doubler feature (option) For RGB analog or component input with composite or tri-level sync sources:...
Page 59: Enhanced Blue On/Off
GUIDED ADJUSTMENT MODE Highlight Line Doubler by push- ing the control disk up or down and press ENTER to toggle P I C T U R E T U N I N G between ON (active) and OFF (non active) S Y N C : FA S T C H R O MA D E LA Y : P A L LI N E D O U B LE R : O N...
Page 60: Raster Centering On Green Crt Faceplate
GUIDED ADJUSTMENT MODE Raster Centering on Green CRT Faceplate The green raster must be centered both horizontally and vertically on the center of the H A ND V S HIFT CRT surface. To center the U S E T H E A R R O W K E Y S green raster, look into the green T O C E N T E R TH E R A S TE R O N T H E FA C E P LA TE O F T H E...
Page 61 GUIDED ADJUSTMENT MODE correct raster position wrong raster position After centering the green raster, press the ENTER key to continue. ENTER continues to Red Raster Shift EXIT returns to Horizontal and Vertical Shift R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 62: Shifting Red And Blue On Green
GUIDED ADJUSTMENT MODE Shifting Red and Blue on Green Use the control disk to shift the red image until the center coincides with the center of the green image. re d or bl ue i m a g e g re en i m a g e When the red image is correctly positioned, press the ENTER key to continue with the blue image.
Page 63: Vertical Centerline Bow Adjustment
GUIDED ADJUSTMENT MODE Vertical Centerline Bow Adjustment Correct by pushing The vertical centerline bow the control disk to adjustment corrects for curva- the right ture in the horizontal direction in the middle of the picture for the vertical lines. Push the control disk to the left or to the right to adjust the Vert ical centerline vertical centerline bow of the...
Page 64: Right Keystone Adjustment
GUIDED ADJUSTMENT MODE Right Keystone Adjustment Correct by pushing The right keystone function the control disk to corrects the keystone geom- the right. etry distortion of the vertical lines on the right side of the image. Push the control disk to the right or to the left to adjust the right keystone (vertical lines) Correct by pushing...
Page 65: Left Bow Adjustment
GUIDED ADJUSTMENT MODE Left Bow Adjustment The left bow function corrects Correct by pushing for curvature occurring the ver- the control disk to tical lines at the left of the dis- the right. played image. Push the control disk to the left or to the right to adjust the left bow of the setup pattern (vertical lines) and press EN-...
Page 66: Top-Bottom (North-South) Adjustments
GUIDED ADJUSTMENT MODE H size too large Correct by pushing the control disk to the left. Ideal image width H size too small Correct by pushing the control disk to the right. Top-Bottom (North-South) Adjustments Top-Bottom adjustments affect only the horizontal lines of the TO P -B O TTO M setup pattern.
Page 67: Horizontal Centerline Skew Adjustment
GUIDED ADJUSTMENT MODE Horizontal Centerline Skew Adjustment The horizontal skew function Correct by pushing corrects for tilting of the hori- the control disk up zontal lines in the middle of the picture. Push the control disk up or down to adjust the horizontal centerline skew of the setup Hor.
Page 68: Top Bow Adjustment
GUIDED ADJUSTMENT MODE Top Bow Adjustment Correct by pushing the control disk up. The top bow function corrects for curvature occurring in the upper part of the image. Adjust the bow of the horizon- tal lines in the upper side of the image by pushing the control disk up or down until these lines are straight.
Page 69: Size-Linearity Adjustment
GUIDED ADJUSTMENT MODE Size-linearity Adjustment Size adjustments affect the height and width of the pro- jected image. The vertical lin- SIZE-L INEARITY earity adjustment is used to A D J U S T V E R TI C A L S I ZE adjust the horizontal lines of A N D LI N E A R I TY , I N O R D E R the setup pattern until the spac-...
Page 70: Vertical Size Adjustment
GUIDED ADJUSTMENT MODE Vertical Size Adjustment Adjust the vertical size by push- ing the control disk up or down until the exact image height is obtained. Note : - if the internal # pattern was selected, this pattern re- mains on the screen. - if the genlocked pattern was V SIZ E selected, the external...
Page 71: Horizontal Phase Adjustment
GUIDED ADJUSTMENT MODE Horizontal Phase Adjustment Note : No horizontal phase adjustment is available on the internal # pattern. For external sources : If the raster shift is correctly adjusted, the text box H phase is projected in the middle of the raster.
Page 72: Convergence Adjustment
GUIDED ADJUSTMENT MODE Convergence Adjustment Convergence adjustments af- fect both the horizontal and vertical lines of the setup pat- C ON V E R G E NC E S T A R T W I T H G R E E N O N L Y , tern.
Page 73: Blanking Adjustment
GUIDED ADJUSTMENT MODE Blanking Adjustment Blanking adjustments affect only the edges of the projected BL AN KI NG image and are used to frame the projected image on to the screen and to hide or black out A D J U S T T H E T O P , B O TT O M , unwanted information (or LE FT A N D R I G H T B L A N K I N G I N O R D E R TO F R A M E...
Page 74: Top Blanking Adjustment
GUIDED ADJUSTMENT MODE Top blanking adjustment Push the control disk up or un wa nt ed in for ma tion (to b e blanked out) down to adjust the top blank- ing of the setup pattern. Press Correct by pushing ENTER to continue.
Page 75: Left Blanking Adjustment
GUIDED ADJUSTMENT MODE Left blanking adjustment Push the control disk to the unwanted information (to be blanked out) right or to the left to adjust the Correct by pushing left blanking of the setup pat- the control disk to tern. the right.
Page 76: Color Balance
GUIDED ADJUSTMENT MODE Color Balance Use the control disk to select between : - Fixed Color Balance (one of C O L O R B A L A N C E the 4 predefined values) FI X E D C O LO R B A LA N C E 3200 4900 6500...
Page 77: Random Access Adjustment Mode
RANDOM ACCESS ADJUSTMENT MODE RANDOM ACCESS ADJUSTMENT MODE Starting up the random access adjustment mode Overview flow chart 'Random Access adjustment mode' Selecting Setup Pattern Internal cross hatch pattern Picture tuning Color balance Sync Fast/Slow Line Doubler Enhanced Blue Geometry adjustments Horizontal phase Raster shift adjustment Left-right adjustments...
Page 78: Starting Up The Random Access Adjustment Mode
RANDOM ACCESS ADJUSTMENT MODE Starting up the random access adjustment mode. Push the control disk up or down to highlight "RANDOM A DJ U S TM E NT M OD E ACCESS" and then press EN- TER. S el ect a pat h f rom be l o w : G U I D E D Some items in the Random...
Page 79: Overview Flowchart 'Random Access Adjustment' Mode
RANDOM ACCESS ADJUSTMENT MODE Overview flowchart 'Random Access Adjustment' mode R A N D O M A C C E S S A D J U S T ME N T MO D E P IC T U R E T U N IN G G E O M E T R Y C O N V E R G E N C E C O L O R S E L E C T...
Page 80 RANDOM ACCESS ADJUSTMENT MODE G E O M E TR Y L E FT- R I G H T H P H A S E V C E N T E R L IN E B O W R A S T E R S H IF T V C E N T E R L IN E S K E W L E FT - R IG HT (E-W) R IG H T B O W...
Page 81: Selecting Setup Pattern
RANDOM ACCESS ADJUSTMENT MODE Selecting Setup Pattern If an external source is con- nected to the projector, the path selection menu will be C h o o s e displayed. Push the control a s et up pat t ern f ro m bel ow : disk up or down to highlight the desired setup pattern and...
Page 82: Internal Cross Hatch Pattern
RANDOM ACCESS ADJUSTMENT MODE Internal Cross Hatch Pattern The Internal # pattern menu will be displayed if the internal cross hatch pattern has been INTERNAL # PATTERN selected or if no source is con- k H z / H z nected to the projector.
Page 83: Picture Tuning
RANDOM ACCESS ADJUSTMENT MODE Picture tuning Highlight Picture tuning by pushing the control disk up or down and press ENTER. PIC TURE TUN ING The Picture tuning menu will be displayed. Depending on the input C O LO R B A LA N C E source, the Picture tuning S Y N C : FA S T LI N E D O U B LE R : O N...
Page 84: Sync Fast/Slow Adjustment
RANDOM ACCESS ADJUSTMENT MODE Custom Color Balance. Select custom white balance by pushing the control disk up or down and press ENTER to start the adjustment. Push the control disk up or down to adjust the red gain and push the control disk to the left or to the right to adjust the blue gain.
Page 85: Line Doubler
RANDOM ACCESS ADJUSTMENT MODE Line Doubler Line doubling is only possible for Video, S-Video or Component Video images on standard line frequency. To eliminate the video line patterns and to improve the image stability, the line doubler has to be switched on. The line doubler is default set in the ON position when starting up for the first time.
Page 86: Color Select
RANDOM ACCESS ADJUSTMENT MODE Color Select Highlight COLOR SELECT by pushing the control disk up R AN D OM AC C ES S and down and press ENTER to A DJ US TM E NT M OD E display the color select menu. P I C TU R E T U N I N G G E O M E T R Y C O N V E R G E N C E...
Page 87: Geometry Adjustments
RANDOM ACCESS ADJUSTMENT MODE Geometry Adjustments The geometry adjustments have to be done only on the green image. These adjustments are automatically implemented for the other color images : Left-right (EW) and Top-Bottom corrections, blanking, Horizontal amplitude, vertical amplitude, vertical linearity and Horizontal phase. Highlight GEOMETRY by pushing the control disk up or R AN D OM AC C ES S...
Page 88: Horizontal Phase Adjustment
RANDOM ACCESS ADJUSTMENT MODE Horizontal Phase Adjustment Push the control disk up or down to highlight H PHASE on Geometry menu and then press G E O M E T R Y ENTER. H P H A S E R A S T E R S H I F T LE FT - R I G H T (E - W ) TO P - B O TT O M ( N - S ) H S I Z E...
Page 89 RANDOM ACCESS ADJUSTMENT MODE Note : - if the genlocked pattern was selected, the external source will be displayed. A bar scale and a number indi- cator (between 0 and 100) on the screen give a visual indica- tion of the horizontal phase ad- justment.
Page 90: Raster Shift Adjustment
RANDOM ACCESS ADJUSTMENT MODE Raster Shift Adjustment The green raster must be centered both horizontally and vertically on the center of the G E O M E T R Y CRT surface. To center the H P H A S E green raster, look into the green R A S T E R S H I F T LE FT - R I G H T (E - W )
Page 91 RANDOM ACCESS ADJUSTMENT MODE c or rect r as ter pos ition wr ong r as ter pos ition Press EXIT to return to the Geometry menu. Note : Horizontal and Vertical shifts for Red and Blue should be end up with a setting close to 50%.
Page 92: Left-Right (East-West) Adjustments
RANDOM ACCESS ADJUSTMENT MODE Left-Right (east-west) Adjustments Left-right and center adjustments affect only the vertical lines of the projected image. To start up the left-right and center adjustments, follow the next procedure : Push the control disk up or down to highlight LEFT-RIGHT (E/W) on the geometry menu G E O M E T R Y and then press ENTER .
Page 93 RANDOM ACCESS ADJUSTMENT MODE Adjust the next alignments until the vertical lines are straight. To enter an alignment, push the control disk up or down to highlight a function and press ENTER to activate Corrects for curvature of the vertical lines in the middle this function.
Page 94: Top-Bottom (North-South) Adjustments
RANDOM ACCESS ADJUSTMENT MODE Top-Bottom (north-south) Adjustments Top-Bottom and center adjustments affect only the horizontal lines of the projected image. To start up the Top-Bottom and center corrections, follow the next procedure : Push the control disk up or down to highlight TOP-BOT- TOM (N/S) on the geometry G E O M E T R Y menu and then press ENTER.
Page 95 RANDOM ACCESS ADJUSTMENT MODE Adjust the next alignments until the vertical lines are straight. To enter an alignment, push the control disk up or down to highlight a function and press ENTER to activate this function. Corrects for curvature of the horizontal lines in the Press EXIT to return.
Page 96: Horizontal Size Adjustment
RANDOM ACCESS ADJUSTMENT MODE Horizontal Size Adjustment Push the control disk up or down to highlight H SIZE on the Geometry menu and then G E O M E T R Y press ENTER . H P H A S E R A S T E R S H I F T LE FT - R I G H T (E - W ) TO P - B O TT O M ( N - S )
Page 97: Vertical Linearity Adjustment
RANDOM ACCESS ADJUSTMENT MODE Vertical Linearity Adjustment The vertical linearity adjust- ment function corrects for ver- tical non-linearities which ex- G E O M E T R Y tend from the center of the im- H P H A S E age to the top and bottom of R A S T E R S H I F T LE FT - R I G H T (E - W )
Page 98: Vertical Size Adjustment
RANDOM ACCESS ADJUSTMENT MODE Vertical Size Adjustment Push the control disk up or down to highlight V SIZE on the Geometry menu and then G E O M E T R Y press ENTER . H P H A S E R A S T E R S H I F T LE FT - R I G H T (E - W ) TO P - B O TT O M ( N - S )
Page 99: Blanking Adjustments
RANDOM ACCESS ADJUSTMENT MODE Blanking Adjustments Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). A 0% on the bar scale indicates no blanking. To start up the Blanking adjustments, follow the next procedure : Push the control disk up or down to highlight BLANKING...
Page 100 RANDOM ACCESS ADJUSTMENT MODE Adjust the next blanking alignments until the image is correctly framed or the unwanted information is blanked out. To enter a blanking alignment, push the control disk up or down to highlight a function and press ENTER to activate this function. Press EXIT to return.
Page 101: Convergence Adjustments
RANDOM ACCESS ADJUSTMENT MODE Convergence Adjustment Convergence adjustments af- fect both the horizontal and vertical lines of the setup pat- C ON V E R G E NC E tern. These adjustments are performed on the red image while superimposed on the G R E E N O N L Y R E D O N G R E E N green image and then on the...
Page 102 RANDOM ACCESS ADJUSTMENT MODE The screen area is divided into 25 areas. Use the control disk to move the box to the desired zone and then press ENTER to begin the convergence adjustment. Start the convergence adjustment with zone one and continue as mentioned in the diagram hereafter.
Page 103: Service Mode
SERVICE MODE SERVICE MODE Starting up the service mode Overview flow chart Service mode Projector Set Up Memory Management Common Settings I2C Diagnostics R5975228 BARCOVISION 701 MULTIMEDIA 070597...
Page 104 SERVICE MODE Starting up the Service mode. Use the control disk to highlight 'Service' and then press ENTER. A D J U S T M E N T M O D E Some items in the Service mode Sel ect a pa th f rom b el ow : are password protected (when the G U I D E D...
Page 105: Overview Flowchart 'Service' Mode
SERVICE MODE Overview flowchart 'Service' mode. SERVICE MODE IDENTIFICATION TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE PROJECTOR SET-UP CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE POWER UP MODE BARCO LOGO COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS MEMORY MANAGEMENT ALL SETTINGS TO MIDPOS R&B CONVERGENCE MID GR CONV.
Page 106: Projector Set Up
SERVICE MODE Projector Set-up Highlight 'Projector Set-Up' by push- ing the control disk up or down and SERVICE MODE press ENTER to display the projector set-up menu. PROJECTOR SET-UP Within the projector set-up menu, the MEMORY MANAGEMENT COMMON SETTINGS following items can be consultated or I2C DIAGNOSTICS set to the desired setting : - Identification...
Page 107: Total Run Time
SERVICE MODE The 'Identification' screen gives in- formation concerning : - Projector address. To change the address of your projector, contact V 701 MULTIMEDIA a qualified service technician. P ro j. a d dr e s s : 00 1 S of t.
Page 108: Change Password
SERVICE MODE Note : all projectors leave the factory after a burn-in period of approximately 100 hours. Change password This item is password protected. Highlight 'Change Password' with the PROJECTOR SET-UP control disk and press ENTER. IDENTIFICATION TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE CHANGE PROJECTOR ADDRESS...
Page 109: Change Language
SERVICE MODE When the displayed password is cor- rect, press ENTER to save. C H A N G E P A S S W O R D If not correct, press EXIT to cancel the saving. Password will be re pr ogr am med a s X XX X. <E NTER >...
Page 110: Change Projector Address
SERVICE MODE Change Projector Address Every projector requires an individual address between O and 255. This PROJECTOR SET-UP address can be software installed. To change that address, push the IDENTIFICATION TOTAL RUN TIME control disk up or down to highlight CHANGE PASSWORD CHANGE LANGUAGE 'Change Porjector Address' and press...
Page 111: Power Up Mode
SERVICE MODE The following baud rates are avail- able : BAUDRATE - 9600 Select new - 4800 baudrate : - 2400 9600 4800 - 1200 2400 1200 - 600 - 300 Select with arrow keys ; - 150 <ENTER> to accept - 110 <EXIT>...
Page 112: Barco Logo
SERVICE MODE BARCO_logo The BARCO logo can be added to the image, in overlay or in background, PROJECTOR SET-UP on any place on the screen. To add the BARCO logo or to change IDENTIFICATION TOTAL RUN TIME a setting in the BARCO logo menu, CHANGE PASSWORD CHANGE LANGUAGE highlight 'BARCO logo' by pushing...
Page 113: Memory Management
SERVICE MODE Memory management Highlight 'Memory management' by pushing the control disk up or down SERVICE MODE and press ENTER to display the memory management menu. PROJECTOR SET-UP Within the memory management MEMORY MANAGEMENT COMMON SETTINGS menu, the following items can be I2C DIAGNOSTICS consultated or executed : - copy a block...
Page 114: Deletion Of Blocks
SERVICE MODE To copy the settings of a closed block to the block you are working on C O P Y M O D E (active block), use the control disk to Nr. Src Fh conf. select a block. 15.6 50 video 31.2 60 RGB3S RT...
Page 115: Deleting Block By Block
SERVICE MODE Deleting block by block MEMORY MANAGEMENT The 'delete a block' function deletes COPY A BLOCK the settings of a selected block. DELETE A BLOCK DELETE ALL BLOCKS Highlight 'Delete a block' with the ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID control disk and press ENTER.
Page 116: Deletion Of All Blocks
SERVICE MODE Deletion of all blocks Highlight 'delete all blocks' with the control disk and press ENTER. MEMORY MANAGEMENT COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID GR CONVERGENCE MID Select with then <ENTER>...
Page 117: Undo All Settings To Midpos
SERVICE MODE ENTER will set all settings to their midposition. EXIT will cancel the ALL SETTIN GS TO M ID POSI TION operation to set all settings to their midposition. All settings in curre nt block wil be overwritten ! <E NTE R>...
Page 118: Undo R & B Convergence Mid
SERVICE MODE ENTER sets the convergence set- tings to their midposition. EXIT can- R & B C O N VER G EN C E M ID cels the procedure to set the conver- gence settings to their midposition. Co n ve r g e n ce s e t t in g s in cu r re nt bloc k wil be o ve rwritt en ! <...
Page 119: Common Settings
SERVICE MODE Undo green convergence mid Only available when the projector is equipped with green conver- MEMORY MANAGEMENT gence adjustmentes. The item 'Undo green convergence COPY A BLOCK DELETE A BLOCK mid' will automatically be displayed DELETE ALL BLOCKS ALL SETTINGS TO MIDPOS when the green convergence is R &...
Page 120: G2 Adjustment
SERVICE MODE G2 Adjustment Item is password protected. Highlight 'G2 adjust' with the control COMMON SETTINGS disk and press ENTER to continue. G2 ADJUSTMENT CRT RUN IN CYCLE PROJECTOR WARM UP Select with then <ENTER> <EXIT> to return. A safety notice will be displayed on the screen as it is necessary to open the top cover to adjust the G2.
Page 121: Crt Run In Cycle
SERVICE MODE CRT run in cycle The CRT run in cycle option can only be activated when memory blocks on an internal # pattern are available. When one or more such blocks are available, a flashing white image (5sec on, 5 sec off) is generated and that for 5 min on the first internal block. In the next 5 min, a second internal block will be used to generate the flashing white image.
Page 122: Projector Warm Up
SERVICE MODE Projector warm up Highlight 'Projector warm up' by push- ing the control disk up or down and COMMON SETTINGS press ENTER to select the projector warm up menu. G2 ADJUSTMENT CRT RUN IN CYCLE PROJECTOR WARM UP Select with then <ENTER>...
Page 123: I2C Diagnostics
SERVICE MODE I2C Diagnostics Highlights 'I2C Diagnostics' by pushing the control disk up or SERVICE MODE down and press ENTER. The I2C diagnostics menu gives PROJECTOR SET-UP an overview of the I2C failures MEMORY MANAGEMENT COMMON SETTINGS inside the projector. I2C DIAGNOSTICS Select with then <ENTER>...
Page 124 SERVICE MODE 9-22 R5975228 BARCOVISION 701 MULTIMEDIA 070597...
Page 125: Messages, Warnings And Failures
MESSAGES, WARNINGS AND FAILURES MESSAGES, WARNINGS AND FAILURES R5975228 BARCOVISION 701 MULTIMEDIA 070497 10-1...
Page 126 MESSAGES, WARNINGS AND FAILURES When selecting a new source, information about this INPUT 01 source will be displayed on the screen. Source number, Fh= 15.6 kHz horizontal and vertical frequencies of the displayed Fv= 050 Hz source. Announcement of the selected source. SOURCE 01 Message to enter your password.
Page 127 MESSAGES, WARNINGS AND FAILURES WARNING : The input is a valid input but the source is not connected to the input terminals or the input source is switched off. source not available WARNING : When a wrong key is pressed on the RCU. invalid key entry WARNING :...
Page 128 MESSAGES, WARNINGS AND FAILURES WARNING : Projector will switch to 'stand-by' when the RCVDS is no longer available. go to stand by WARNING : The entered frequency or applied frequency of the invalid source is out of the projector's range. frequency input Message to inform that selected table is deleted.
Page 129: Options
OPTIONS OPTIONS IR receiver 800 Hardwired RCU Projector Control software RCVDS 05 VS05 Adapter and communication cables Ceiling mount CM50 Soft edge matching Contrast modulation Picture Orbiting R5975238 BARCOVISION 701 MULTIMEDIA 070497 11-1...
Page 130 OPTIONS IR Receiver 800 This infrared receiver unit makes it possible to control the projector from another room. There is a communication line with cable between the IR receiver and the projector or the RCVDS05. The control information from the RCU can now be sent to this IR receiver.
Page 131 OPTIONS Projector Control software Only available for projectors equipped with the optional RS232 communication port. The software is user-friendly and makes full use of : mouse control, pull down menus and dialog boxes. Two main applications are available with this software : remote control and transferring and receiving data of projector settings.
Page 132: Orbiting Kit
OPTIONS b. Din Mini8-D9 adapter cable. - To connect a Macintosh computer to the projector. Available length : 1 m, order number R9827640. c. D25-D9 adapter cable - To connect a workstation to the projector. Available length : 1 m, order number R9827630 Ceiling mount CM50 This suspension system enables to mount any projector from the BARCO 700 series to the ceiling without using any mechanical interface, and to adapt the projector...
Page 133: Appendix A : Battery Replacement In The Rcu
APPENDIX A : BATTERY REPLACEMENT IN THE RCU Battery replacement in the RCU. Remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU. Lift up the top side of the cover at the same time (fig.
Page 134 APPENDIX A : BATTERY REPLACEMENT IN THE RCU R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 135: Appendix B : Orbiting
APPENDIX B : ORBITING Orbiting (option) Static pictures are very often shown on large screen projectors, especially in process control and presentation applications. Due to the fact that the same picture information is shown for a long period on the same place, picture tubes can be damaged by 'local burn-in'.
Page 136 APPENDIX B : ORBITING Master/slave toggle Highlight 'CHANGE TO SLAVE' with the control disk and press ENTER to set the projector as M A S T E R O R B I T I N G C H A N G E T O S L A V E Slave.
Page 137 APPENDIX B : ORBITING Orbiting speed toggle (only in MASTER Orbiting) Highlight 'SPEED : SLOW' with the coontrol disk and press EN- TER to set the ORBITING SPEED M A S T E R O R B I T I N G C H A N G E TO S L A V E to Fast.
Page 138 APPENDIX B : ORBITING When adjusting the horizontal and the vertical deviation, the picture moves in the corresponding direction, allowing the set up of the deviation without orbiting operation. Push the control disk to the left (right) or up (down) to toggle be- tween Hor.
Page 139 APPENDIX B : ORBITING Adjustment procedure multiple projector installations : Important : to allow corrections in the deviation alignments of the slave projectors, never adjust the deviations of the master projector to its maximum. Default setting of the Master projector see 'Stand alone projector'. Highlight 'ADJUST DEVIATION' with the control disk and press ENTER.
Page 140 APPENDIX B : ORBITING R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 141: Appendix C : Soft Edge Matching
APPENDIX C : SOFT EDGE MATCHING Soft edge matching (option) Multi-screens are popular for many applications. In these installations, the goal is to obtain a contiguous matched image, forming one homogenous view. The soft edge matching feature provides a solution to the annoying side effects when adjusting two or more projected images next to each other.
Page 142 APPENDIX C : SOFT EDGE MATCHING Basic concept total light output 1 0 0 % light output per image 1 0 0 % 5 0 % Image 1 Image 2 adjustable overlapping area Adjustment procedure : Start up the adjustment mode by pressing ADJUST (see also chapter 'Start up of the adjustment mode') Highlight Random access with the control disk and press ENTER to start up the Random Access Adjustment mode (see also chapter Random Access Adjustment...
Page 143 APPENDIX C : SOFT EDGE MATCHING Each overlap area (left and right) is determined by a start (stop) position and an area width. The start (stop) position for the top (bottom) overlap area is determined by the blanking adjustment. Highlight ' H TEST MODE ' and press ENTER .
Page 144 APPENDIX C : SOFT EDGE MATCHING Start position Highlight START POSITION with the control disk and press ENTER. S O F T E D G E C O R R E C T I O N S T A R T T O P S TAR T L EFT R IG H T STO P B O T T O M...
Page 145 APPENDIX C : SOFT EDGE MATCHING Left image area Highlight LEFT with the control disk and press ENTER. The normal image superimposed S O F T E D G E C O R R E C T I O N with the test pattern will be dis- S T A R T played.
Page 146 APPENDIX C : SOFT EDGE MATCHING Stop position Highlight STOP POSITION with the control disk and press ENTER. S O F T E D G E C O R R E C T I O N S T A R T T O P S T A R T L E FT R I G H T S TO P B O T T O M...
Page 147 APPENDIX C : SOFT EDGE MATCHING Right image area Highlight LEFT with the control disk and press ENTER. S O F T E D G E The normal image, superimposed C O R R E C T I O N with the test pattern will be dis- S T A R T played.
Page 148 APPENDIX C : SOFT EDGE MATCHING Vertical test mode Highlight 'V TEST MODE' and press ENTER. S O F T E D G E The test image is enabled to adjust C O R R E C T I O N the start (stop) position and the S T A R T area width.
Page 149 APPENDIX C : SOFT EDGE MATCHING Top soft edge area adjustment Highlight TOP with the control disk and press ENTER. S O F T E D G E The normal image, superimposed C O R R E C T I O N with the test pattern will be dis- S T A R T played.
Page 150 APPENDIX C : SOFT EDGE MATCHING Bottom soft edge area adjustment Highlight BOTTOM with the con- trol disk and press ENTER. The normal image, superimposed S O F T E D G E C O R R E C T I O N with the test pattern will be dis- S T A R T played.
Page 151: Appendix D : Contrast Modulation (Option
APPENDIX D : CONTRAST MODULATION Contrast modulation (option) Today multi-screens are very popular for many applications e.g. simulation busi- ness. In these installations, the goal is to obtain a continuous matched image, forming one homogeneous view. The viewer wants to see an overall light output uniformity.
Page 152: Adjustment Procedure
APPENDIX D : CONTRAST MODULATION Basic concept WITHOUT CONTRAST MODULATION WITH CONTRAST MODULATION horizontal light output horizontal light output C O RN E R C OR NE R 1 00 % 1 00 % FA LL O FF FA LL O FF 5 0 % 5 0 % I m a ge...
Page 153 APPENDIX D : CONTRAST MODULATION The first 3 adjustments (horizontal red, green and blue) are used for C O N T R A S T horizontal light equalisation for the E Q U A L I S A T I O N three specific colors separately.
Page 154 APPENDIX D : CONTRAST MODULATION Highlight VERTICAL with the con- trol disk and press ENTER. This C O N T R A S T adjustment is done for all three E Q U A L I S A T I O N colors at the same time.
Page 155 APPENDIX D : CONTRAST MODULATION Highlight TOP-BOTTOM with the control disk and press ENTER to C O N T R A S T start the vertical 'hot spot' cor- E Q U A L I S A T I O N rection in the center of the R E D H O R I ZO N TA L G R E E N H O R I ZO N TA L...
Page 156 APPENDIX D : CONTRAST MODULATION R5975238 BARCOVISION 701 MULTIMEDIA 070497...
Page 157: Appendix E : Adjustment Blocks (Memory Blocks
APPENDIX E : ADJUSTMENT BLOCKS Adjustment Blocks (memory blocks) As the BARCOVISION 701 MULTIMEDIA is digitally controlled, all geometry and convergence adjustments are stored in the projector’s memory as numeric values. These numeric values are used to control digital potentiometers which in turn, control the projector.
Page 158 APPENDIX E : ADJUSTMENT BLOCKS blocks available, the projector dis- plays a warning. W A R N I N G Al l me mo ry b lo ck s ar e Press ENTER to continue and start u s e d . Pl eas e, go to t he up the adjustment mode to delete a se rvi ce mo de, de le te a...
Page 159: Appendix F : Source Numbers 90 - 99
APPENDIX F : SOURCE NUMBERS 90 - 99 Source numbers 90 - 99 Source numbers 90 - 99 do not correspond to physical inputs to the projector or RCVDS05. They are used to assign an additional adjustment block to a source. This additional adjustment block may contain different geometry and convergence set- tings, sync fast/slow positions and enhanced blue on/off settings.
Page 160 APPENDIX F : SOURCE NUMBERS 90 - 99 Follow the steps below to create a second adjustment block for a source between 0 and 9. 1. Select the source between 0 and 9 that the second adjustment block is to be created for.
Page 161 R C U R C U INPU T SO UR CES INPUT S O URCES PR O J EC TO R PR O J EC TO R INPU T SO UR CES INPU T SO UR CES R C V D S R C V D S R5975238 BARCOVISION 701 MULTIMEDIA 070497...
