Carton Inventory
Your garage door opener is packaged in one carton which contains the motor unit and all parts
illustrated below. Accessories vary depending on the garage door opener model purchased. Depending
on your model, other accessories may be included with your garage door opener. Instructions for these
accessories will be attached to the accessory and are not included in this manual. If anything is missing,
carefully check the packing material. Hardware for assembly and installation is shown on the next page.
Save the carton and packing material until the installation and adjustment is complete. The images
throughoutthis manual are for reference only and your product may look different.
A.
Headerbracket
B.
PulIey
C.
Door bracket
D.
Carveddoor arm
E.
Straightdoorarm
(Packagedinside front rail section)
F.
Trolley
NOTE: Be sure to assemblethe trolley beforesliding ontorail.
G.
Emergencyreleaseropeand handle
H.
Rail (1 front and 4 centersections)
I.
Hangingbrackets (2)
(Packagedinside the front rail section)
J.
Garagedoor opener(motor unit)
K.
Sprocketcoverand screws
L.
"U" bracket
M.
Belt
N.
Door control
O.
Remotecontrol
P.
The ProtectorSystem ®
Safetyreversingsensors with 2 conductorwhite and white/blackwire attached:SendingSensor (1),
Receiving Sensor(1), andSafety SensorBrackets (2)
NOT SHOWN
Whiteand red/white wire
Owner'smanual
