Cannot adjust printhead.

Messages regarding printheads

Messages regarding printheads
Cannot adjust printhead. .................................................................................................................................... 646

Wrong printhead. ............................................................................................................................................... 646

Printhead error ................................................................................................................................................... 646

No printhead ...................................................................................................................................................... 646

Execute printhead cleaning. .............................................................................................................................. 646

Cannot adjust printhead. Cannot adjust printhead.
Cause
The Printhead nozzles are clogged.
The Printhead cannot be aligned; highly
transparent film is loaded.
The Printhead is installed crooked.
Wrong printhead.
Wrong printhead.
An incompatible Printhead has been installed.
Printhead error
Printhead error
Cause
There is a problem with the Printhead.
No printhead
No printhead
Cause
No Printhead is installed.
646 Execute printhead cleaning.
Execute printhead cleaning.
Cause
The Printhead noz-
zles are clogged.
Execute Head Posi. Adj. again, as follows.
1.
Press the OK button to clear the error.
2.
Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.")
3.
Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.")
4.
Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
Straighten the Printhead as follows, and then execute Head Posi. Adj. again.
1.
Press the OK button to clear the error.
2.
Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment (Head Inc. Adj.).")
3.
Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).")
Cause
Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
Corrective Action
Install the Printhead.
(See "Replacing the Printhead.")
Follow these steps to clean the Printhead.
Corrective Action
→P.575
→P.576
Corrective Action
→P.577
Corrective Action
→P.577
→P.577
Corrective Action
→P.552
→P.552
→P.555
→P.552
