Prints using Folded Duplex

Prints using Folded Duplex

Prints using Folded Duplex
This prints 2 pages consecutively. Folding back the paper at the fold lines of the center substitutes for duplex printing.
1
Select two objects from the layout area of Free Layout.
2
Select Folded Duplex from the Edit menu of Free Layout.
Open the Folded Duplex window and arrange the selected objects in the layout area.
3
Open the Finished Size Settings dialog box from the Edit menu.
4
Select Fit Roll Paper Width or Specify Folded Size in Finished Size.
•
Note
5
Click OK to save the settings.
6
Open the Binding Settings dialog box from the Edit menu.
7
Select Bottom or Top in Binding Edge.
8
Specify the Binding width in Binding.
9
Configure the Fold Line Color and Fold Line Type from Print Fold Lines.
•
Note
10
Click OK to save the settings.
11
Confirm the print setting and begin printing.
240
Rotate Page 90 degrees (Conserve Paper) is also available when Specify Folded Size is selected.
When the Only Print Center and Edges checkbox is selected, fold lines are only printed at the three locations of the
center and both edges.
