Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.)
Manual adjustment requires you to examine the printed test pattern and enter an adjustment value.
•
Manual may be unavailable in some cases, even if it is displayed in the menu.
If so, execute Auto(Advanced) once.
Note
•
Always make sure the loaded paper matches the type of paper specified on the printer. Adjustment cannot be completed
correctly unless the loaded paper matches the settings.
•
We recommend using the type of paper you use most often for adjustment.
Paper to Prepare
Rolls An unused roll at least 10 inches wide
Sheets One sheet of unused paper of at least A4/Letter size
Perform adjustment as follows.
1
Load the paper.
• Attaching the Roll Holder to Rolls
•
Loading Rolls in the Printer
• Loading Sheets in the Printer
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
•
Note
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
Press ▲ or ▼ to select Head Posi. Adj., and then press the OK button.
6
Press ▲ or ▼ to select Manual, and then press the OK button.
A test pattern is printed for adjustment.
7
554 Press ▲ or ▼ to select D, and then press the OK button.
8
Press ▲ or ▼ to select D-1, and then press the OK button.
→P.442
→P.461
).
If the Tab Selection screen is not displayed, press the Menu button.
→P.439
